2: Installing the HR2000+
8 294-00000-000-02-201012
3. Verify that the calibration coefficients match the coefficients from the Wavelength Calibration
Data Sheet that accompanied the spectrometer. If necessary, modify these values using the USB
Programmer utility.
4. Additionally, ensure that you select both the Master and Channel Enabled boxes.
5. In the A/D Interface tab, enter the same values as in the Configure Hardware screen.
OOIBase32 stores this information for future use once you close the program.
Connect Spectroscopic Accessories
To find operating instructions for HR2000+-compatible products (such as light sources, sampling
chambers, and probes), consult the Software and Technical Resources CD or the Ocean Optics website at
http://www.oceanoptics.com/technical/operatinginstructions.asp .
External Triggering Options
You can trigger the HR2000+ using a variety of External Triggering options through the 30-pin
Accessory Connector on the spectrometer. For HR2000+ firmware versions below 3.0, see the External
Triggering Options document located at
http://www.oceanoptics.com/technical/external-
triggering.pdf. For HR2000 + firmware version 3.0 and above, see the External Triggering Options
document located at ???. The triggering document contains instructions for configuring External
Triggering options for the HR2000+.
