1: Introduction
294-00000-000-02-201012 3
5. The spectrometer measures the amount of light and transforms the data collected by the
spectrometer into digital information.
6. The spectrometer passes the sample information to SpectraSuite.
7. SpectraSuite compares the sample to the reference measurement and displays processed spectral
information.
Modular Sampling Accessories
Ocean Optics offers a complete line of spectroscopic accessories for use with the HR2000+. Most of our
spectroscopic accessories have SMA connectors for application flexibility. Accordingly, changing the
sampling system components is as easy as unscrewing a connector and replacing an accessory.
Interface Options
The HR2000+ has both USB and serial port connectors (with the use of an adapter), enabling you to
connect the spectrometer to a desktop or notebook PC via a USB port.
Computer
Interface
Operating System
Requirements
Part Needed Description of Part
Desktop or
Notebook PC
via USB Port
Windows 98/Me/
2000/XP USB-CBL-1
(included) Cable that connects from USB port on HR2000+ to
USB port on desktop or notebook PC
Desktop or
Notebook PC
via Serial Port Any 32-bit
Windows
operating system HR4-
BREAKOUT
(not included)
Adapter block that enables connection from serial port
on HR2000+ to serial port on desktop or notebook PC;
comes with 5 VDC power supply (required when
connecting to serial port). User must supply own
software.
Breakout Box
Ocean Optics also offers the Breakout Box (HR4-BREAKOUT), a passive module that separates the
signals from their 30-pin port to an array of standard connectors and headers, enabling easy access to a
variety of features found in Ocean Optics’ HR2000+ Spectrometer. In addition to the accessory
connector, the breakout box features a circuit board based on a neutral breadboard pattern that allows
custom circuitry to be prototyped on the board itself.
