Teccor ® brand Thyristors
EV Series 1.5 Amp Sensitive SCRs
Sx02xS Series
Electrical Characteristics (T
J
= 25°C, unless otherwise specified)
Static Characteristics (T
J
= 25°C, unless otherwise specified)
Symbol Description Test Conditions
Sx02xS
Unit
Min Max
I
GT
DC Gate Trigger Current
V
D
= 12V
R
L
= 60 :
15 200 μA
V
GT
DC Gate Trigger Voltage — 0.8 V
V
GRM
Peak Reverse Gate Voltage I
RG
= 10μA 5 — V
I
H
Holding Current R
GK
= 1 k : — 5 mA
(dv/dt)s
Critical Rate-of-Rise of
Off-State Voltage
T
J
= 125°C
V
D
= V
DRM
/ V
RRM
Exponential Waveform
R
GK
= 1 k :
25 — V/μs
t
q
Turn-Off Time
T
J
= 125°C @ 600 V
R
GK
= 1 k :
— 35 μs
t
gt
Turn-On Time
I
G
= 10mA
PW = 15μsec
I
T
= 3.0A (pk)
— 3 μs
Symbol Description Test Conditions
Value
Unit
Min Max
V
TM
Peak On-State Voltage I
TM
= 3.0A (pk) — 1.70 V
I
DRM
Off-State Current, Peak Repetitive
T
J
= 25°C @ V
D
= V
DRM
R
GK
= 1 k :
— 5 μA
T
J
= 125°C @ V
D
= V
DRM
R
GK
= 1 k :
— 500 μA
Thermal Resistances
Symbol Description Test Conditions Value Unit
R
th(j-c)
Junction to case (AC) I
T
= 1.5A
(RMS)
1
TO-92 50
°C/W
SOT-223 25
R
th(j-a)
Junction to ambient I
T
= 1.5A
(RMS)
1
TO-92 160
°C/W
SOT-223 60
1 60Hz AC resistive load condition, 100% conduction.
