Teccor ® brand Thyristors
8 Amp Sensitive & Standard SCRs
Sxx08xSx & Sxx08x Series
Electrical Characteristics (T
J
= 25°C, unless otherwise specified) – Sensitive SCRs
Symbol Test Conditions
Value
Unit
Sxx08xS2 Sxx08xS3
I
GT V
D
= 6V R
L
= 100 :
MAX. 200 500 μA
V
GT
MAX. 0.8 V
dv/dt V
D
= V
DRM
; R
GK
= 1kΩ; T
J
= 110°C TYP. 8 V/μs
V
GD
V
D
= V
DRM
R
L
= 3.3 k : T
J
= 110°C MIN. 0.2 V
V
GRM
I
GR
= 10μA MIN. 6 V
I
H
I
T
= 20mA (initial) MAX. 6 8 mA
t
q
I
T
=2A; t
p
=50μs; dv/dt=5V/μs; di/dt=-30A/μs MAX. 50 45 μs
t
gt
I
G
= 2 x I
GT
PW = 15μs I
T
= 12A TYP. 4 5 μs
Note: xx = voltage x = package
Electrical Characteristics (T
J
= 25°C, unless otherwise specified) – Standard SCRs
Symbol Test Conditions
Value
Unit
Sxx08x
I
GT V
D
= 12V R
L
= 60 :
MAX. 15 mA
V
GT
MAX. 1.5 V
dv/dt
V
D
= V
DRM
; gate open; T
J
= 100°C
400V
MIN.
350
V/μs
600V 300
800V 250
1000V 100
V
D
= V
DRM
; gate open; T
J
= 125°C
400V 250
600V 225
800V 200
V
GD
V
D
= V
DRM
R
L
= 3.3 k : T
J
= 125°C MIN. 0.2 V
I
H
I
T
= 200mA (initial) MAX. 30 mA
t
q
I
T
=2A; t
p
=50μs; dv/dt=5V/μs; di/dt=-30A/μs MAX. 35 μs
t
gt
I
G
= 2 x I
GT
PW = 15μs I
T
= 16A TYP. 2 μs
Note: xx = voltage x = package
Static Characteristics
Symbol Test Conditions Value Unit
V
TM
I
T
= 16A; t
p
= 380 μs MAX. 1.6 V
I
DRM
/ I
RRM
V
DRM
= V
RRM
Sxx08xyy
T
J
= 25°C 400 - 600V
MAX.
5
μA
T
J
= 110°C 400 - 600V 250
Sxx08x
T
J
= 25°C
400 - 800V 10
1000V 20
T
J
= 100°C
400 - 800V 200
1000V 3000
T
J
= 125°C 400 - 800V 500
Note: xx = voltage, x = package, yy = sensitivity
