Teccor ® brand Thyristors
8 Amp Sensitive & Standard SCRs
Sxx08xSx & Sxx08x Series
Product Selector
Part Number
Voltage
Gate Sensitivity Type Package
400V 600V 800V 1000V
Sxx08RS2 X X 0.2mA Sensitive SCR TO-220R
Sxx08LS2 X X 0.2mA Sensitive SCR TO-220L
Sxx08VS2 X X 0.2mA Sensitive SCR TO-251
Sxx08DS2 X X 0.2mA Sensitive SCR TO-252
Sxx08RS3 X X 0.5mA Sensitive SCR TO-220R
Sxx08LS3 X X 0.5mA Sensitive SCR TO-220L
Sxx08VS3 X X 0.5mA Sensitive SCR TO-251
Sxx08DS3 X X 0.5mA Sensitive SCR TO-252
Sxx08R X X X X 15mA Standard SCR TO-220R
Sxx08L X X X X 15mA Standard SCR TO-220L
Sxx08V X X X X 15mA Standard SCR TO-251
Sxx08D X X X X 15mA Standard SCR TO-252
Note: xx = Voltage
Packing Options
Part Number Marking Weight Packing Mode Base Quantity
Sxx08L/Ryy Sxx08L/Ryy 2.2 g Bulk 500
Sxx08L/RyyTP Sxx08L/Ryy 2.2 g Tube 500 (50 per tube)
Sxx08DyyTP Sxx08Dyy 0.3 g Tube 750 (75 per tube)
Sxx08DyyRP Sxx08Dyy 0.3 g Embossed Carrier 2500
Sxx08VyyTP Sxx08Vyy 0.4 g Tube 750 (75 per tube)
Sxx08L/R Sxx08L/R 2.2 g Bulk 500
Sxx08L/RTP Sxx08L/R 2.2 g Tube 500 (50 per tube)
Sxx08DTP Sxx08D 0.3 g Tube 750 (75 per tube)
Sxx08DRP Sxx08D 0.3 g Embossed Carrier 2500
Sxx08VTP Sxx08V 0.4 g Tube 750 (75 per tube)
Note: xx = Voltage; yy = Sensitivity
