Surface Mount – 3000W > SMDJ-HR series
SMDJ-HR Series
Electrical Characteristics
Part
Number
(Uni)
Part
Number
(Bi)
Marking
Reverse
Stand off
Voltage
V
R
(Volts)
Breakdown
Voltage V
BR
(Volts) @ I
T
Test
Current
I
T
(mA)
Maximum
Clamping
Voltage V
C
@ I
pp
(V)
Maximum
Peak
Pulse
Current I
pp
(A)
Maximum
Reverse
Leakage I
R
@ V
R
(µA)
Agency
Approval
UNI BI MIN MAX
SMDJ5.0A-HR SMDJ5.0CA-HR RDE DDE 5.0 6.40 7.00 10 9.2 326.1 800 X
SMDJ6.0A-HR SMDJ6.0CA-HR RDG DDG 6.0 6.67 7.37 10 10.3 291.3 800 X
SMDJ6.5A-HR SMDJ6.5CA-HR RDK DDK 6.5 7.22 7.98 10 11.2 267.9 500 X
SMDJ7.0A-HR SMDJ7.0CA-HR PDM DDM 7.0 7.78 8.60 10 12.0 250.0 200 X
SMDJ7.5A-HR SMDJ7.5CA-HR PDP DDP 7.5 8.33 9.21 1 12.9 232.6 100 X
SMDJ8.0A-HR SMDJ8.0CA-HR PDR DDR 8.0 8.89 9.83 1 13.6 220.6 50 X
SMDJ8.5A-HR SMDJ8.5CA-HR PDT DDT 8.5 9.44 10.40 1 14.4 208.3 20 X
SMDJ9.0A-HR SMDJ9.0CA-HR PDV DDV 9.0 10.00 11.10 1 15.4 194.8 10 X
SMDJ10A-HR SMDJ10CA-HR PDX DDX 10.0 11.10 12.30 1 17.0 176.5 5 X
SMDJ11A-HR SMDJ11CA-HR PDZ DDZ 11.0 12.20 13.50 1 18.2 164.8 2 X
SMDJ12A-HR SMDJ12CA-HR PEE DEE 12.0 13.30 14.70 1 19.9 150.8 2 X
SMDJ13A-HR SMDJ13CA-HR PEG DEG 13.0 14.40 15.90 1 21.5 139.5 2 X
SMDJ14A-HR SMDJ14CA-HR PEK DEK 14.0 15.60 17.20 1 23.2 129.3 2 X
SMDJ15A-HR SMDJ15CA-HR PEM DEM 15.0 16.70 18.50 1 24.4 123.0 2 X
SMDJ16A-HR SMDJ16CA-HR PEP DEP 16.0 17.80 19.70 1 26.0 115.4 2 X
SMDJ17A-HR SMDJ17CA-HR PER DER 17.0 18.90 20.90 1 27.6 108.7 2 X
SMDJ18A-HR SMDJ18CA-HR PET DET 18.0 20.00 22.10 1 29.2 102.7 2 X
SMDJ20A-HR SMDJ20CA-HR PEV DEV 20.0 22.20 24.50 1 32.4 92.6 2 X
SMDJ22A-HR SMDJ22CA-HR PEX DEX 22.0 24.40 26.90 1 35.5 84.5 2 X
SMDJ24A-HR SMDJ24CA-HR PEZ DEZ 24.0 26.70 29.50 1 38.9 77.1 2 X
SMDJ26A-HR SMDJ26CA-HR PFE DFE 26.0 28.90 31.90 1 42.1 71.3 2 X
SMDJ28A-HR SMDJ28CA-HR PFG DFG 28.0 31.10 34.40 1 45.4 66.1 2 X
SMDJ30A-HR SMDJ30CA-HR PFK DFK 30.0 33.30 36.80 1 48.4 62.0 2 X
SMDJ33A-HR SMDJ33CA-HR PFM DFM 33.0 36.70 40.60 1 53.3 56.3 2 X
SMDJ36A-HR SMDJ36CA-HR PFP DFP 36.0 40.00 44.20 1 58.1 51.6 2 X
SMDJ40A-HR SMDJ40CA-HR PFR DFR 40.0 44.40 49.10 1 64.5 46.5 2 X
SMDJ43A-HR SMDJ43CA-HR PFT DFT 43.0 47.80 52.80 1 69.4 43.2 2 X
SMDJ45A-HR SMDJ45CA-HR PFV FVH 45.0 50.00 55.30 1 72.7 41.3 2 X
SMDJ48A-HR SMDJ48CA-HR PFX FXH 48.0 53.30 58.90 1 77.4 38.8 2 X
SMDJ51A-HR SMDJ51CA-HR PFZ FZH 51.0 56.70 62.70 1 82.4 36.4 2 X
SMDJ54A-HR SMDJ54CA-HR RGE GEH 54.0 60.00 66.30 1 87.1 34.4 2 X
SMDJ58A-HR SMDJ58CA-HR PGG GGH 58.0 64.40 71.20 1 93.6 32.1 2 X
SMDJ60A-HR SMDJ60CA-HR PGK GKH 60.0 66.70 73.70 1 96.8 31.0 2 X
SMDJ64A-HR SMDJ64CA-HR PGM GMH 64.0 71.10 78.60 1 103.0 29.1 2 X
SMDJ70A-HR SMDJ70CA-HR PGP GPH 70.0 77.80 86.00 1 113.0 26.5 2 X
SMDJ75A-HR SMDJ75CA-HR PGR GRH 75.0 83.30 92.10 1 121.0 24.8 2 X
SMDJ78A-HR SMDJ78CA-HR PGT GTH 78.0 86.70 95.80 1 126.0 23.8 2 X
SMDJ85A-HR SMDJ85CA-HR PGV GVH 85.0 94.40 104.00 1 137.0 21.9 2 X
SMDJ90A-HR SMDJ90CA-HR PGX GXH 90.0 100.00 111.00 1 146.0 20.5 2 X
SMDJ100A-HR SMDJ100CA-HR PGZ GZH 100.0 111.00 123.00 1 162.0 18.5 2 X
SMDJ110A-HR SMDJ110CA-HR PHE HEH 110.0 122.00 135.00 1 177.0 16.9 2 X
SMDJ120A-HR SMDJ120CA-HR PHG HGH 120.0 133.00 147.00 1 193.0 15.5 2 X
SMDJ130A-HR SMDJ130CA-HR PHK HKH 130.0 144.00 159.00 1 209.0 14.4 2 X
Note:
1. For bidirectional type having V
R
of 10 volts and less, the I
R
limit is double.
2. 100% High Temperature Storage Life test and Reflow Simulation.
3. 100% HTRB(High Temperature Reverse Bias). For Unidirectional, 150C/100%VR/96hours,
for Bidirectional, 150C/100%VR/192hrs(96hours for each direction for Bidirectional).
4. Each lot of parts will pass group B test requirement.
