47 DriveRack® User Manual
Section 5
Utilities/Meters
5.2.1 - Meters
To meter various aspects of the 260, press and hold the UTILITY button until the display enters
the Metering section.
• Use the PREV PG or NEXT PG button to move to the page that appears as follows:
INS COMP o+
1
INS
2
-30-20 0 +20
- A
B
A
B
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
1
2
3
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
4
5
6
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
1
2
3
Zone Controllers
Panel 1
Panel 2
Panel 3
Zone Controllers
Panel 4
Panel 5
Panel 6
Output Trims
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
4
5
6
Output Trims
This page meters the gain reduction of any Dynamic block configured in the Insert 1 or Insert
2 block.
• Use the PREV PG or NEXT PG button to move to the page that appears as follows:
INS COMP o+
1
INS
2
-30-20 0 +20
- A
B
A
B
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
1
2
3
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
4
5
6
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
1
2
3
Zone Controllers
Panel 1
Panel 2
Panel 3
Zone Controllers
Panel 4
Panel 5
Panel 6
Output Trims
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
4
5
6
Output Trims
This page meters the gain reduction being applied by the Dynamics modules on outputs 1-3.
Pressing the NEXT PG button displays outputs 4-6.
• Use the PREV PG or NEXT PG button to move to the page that appears as follows:
INS COMP o+
1
INS
2
-30-20 0 +20
- A
B
A
B
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
1
2
3
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
4
5
6
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
1
2
3
Zone Controllers
Panel 1
Panel 2
Panel 3
Zone Controllers
Panel 4
Panel 5
Panel 6
Output Trims
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
4
5
6
Output Trims
This (as well as the next) page shows any activity (such as level changes and program changes)
being made by any connected ZC wall panels. Use the PREV PG or NEXT PG button to move
to the page that appears as follows:
INS COMP o+
1
INS
2
-30-20 0 +20
- A
B
A
B
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
1
2
3
LIM 0+
LIM
LIM
-30-20 0 +20
-
0+ -
0+ -
4
5
6
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
1
2
3
Zone Controllers
Panel 1
Panel 2
Panel 3
Zone Controllers
Panel 4
Panel 5
Panel 6
Output Trims
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
Trim 0.0 Net 0.0 dB
4
5
6
Output Trims
This (as well as the next) page displays the Trim and Net (Crossover gains + ZC gains) levels
within the output section.
