18
DriveRack
®
DriveRack® User Manual
Section 2
2.9 Navigating the Wizard Section
Navigating the Delay Section
Delay - On/Off
Length - Delay Time - Course, Fine
Units - Seconds,Feet,Meters
DELAY
DELAY
From program mode, press the Delay button. Pressing the Data Wheel will select the effect parameter to be edited.
Successive Presses of the Delay button will move you through pre and post crossover delays.
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
AFS On/Off
AFS Clear Mode - Fixed/Live
Type- Speech, Low,Med and High Number of filters 0-12
Number of filters fixed 0-12 Live filter Lift - On/Off
Lift After - 0-60
NEXT PG>
The NEXT and PREV
buttons scroll through
the pages of selected module.
NEXT PG>
The NEXT and PREV
buttons scroll through
the pages of selected module.
Navigating the I/O Section
Input Level 1 -Inf to 20dB
Input Level 2 -Inf to 20dB
Master Level -Inf to 20dB Pink Noise On/Off
Pink Noise Level -10 to 10dB Output Channel 1-6 On/Off
Polarity +/-
Phase -180 to 0
FEEDBACK
I/O Section
From program mode, press the I/O button. Pressing the Data Wheel will select the effect parameter to be edited.
NEXT PG>
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
The NEXT and PREV
buttons scroll through
the pages of selected module.
Navigating the Other Section
Subharmonic Synthesizer OTHER
OTHER
From program mode, press the Other button. Successive presses of the Other button will move you to each of the various insert modules available.
Pressing the Data Wheel will select the effect parameter to be edited.
NEXT PG>
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
The NEXT and PREV
buttons scroll through
the pages of selected module.
Navigating the WIZARD Section
RTA/WIZARD
SYSTEM SETUP
AUTO EQ WIZARD
AFS WIZARD
GEQ Setup-Dual Mono
or Stereo Linked Main Speaker Select-
See list Sub Speaker Select-
See list
Amp Select-
High, Mid, Low
See list Amp Sensitivity-
High, Mid, Low Amp Level
High, Mid, Low Low Amp
Bridged/
Normal-
Load New
Program-
Insert 1 Setup-
Select Insert 2 Setup-
Select
Noise gate-
AGC- Limiter Limiter 4-6
Connect Mic Pink Noise Level
-Inf to 20dB Auto EQ - L Auto EQ - R Auto EQ - L-R
Left and Right when using
Linked Graphic EQ
Select Number of
Fixed Filters
- 0-12 Mixer gain turn
down prompt Select Type -
Low, Med, High mode Mixer Gain Adjust-
WIZARD
From program mode, press the RTA/WIZARD button. Pressing the Data Wheel will select the effect parameter to be edited.
NEXT PG>
Fixed Filter Setup
Done-
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
Navigating the Utility/Meters Section
LCD Contrast 1-16
AEQ Plot - RTA/GEQ
UTILITY
PUP Prog. - Current/Stored
PUP Mute - Current/Stored ZC Panel - 1-6
(Store) - Edit Panel Security Level - Module Select
Security Level- Low, Med, High
260 Device Level-
Low, Med, High Edit High Password
Edit Medium Password Program List Size- 1-10
List Index - 1-10 Program Change mode
Normal/Program
Program Number Lock 1-25
Output Jumpers - 1-6
Setting - 14, 22, 30dB
UTILITY
METERS
From program mode, press the UTILITY button. Pressing the Data Wheel will select the effect parameter to be edited.
Pressing and holding the Utility button will enter you into the meter mennu
Navigating the Subharmonic Synthesizer Section
Subharmonic - -On/Off
Subharmonics % 0-100
24-36Hz Level - 24-36Hz
36-56Hz Level - 36-56Hz
Subharmonic
SUBHARMONIC
From program mode, press the SUBHARMONIC button. Pressing the Data Wheel will select the effect parameter to be edited.
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
Advanced Feedback Suppression (AFS) OTHER
Notch- On - Off
Flatten/Restore
Notch Filter OTHER
Freq 1-6 19.7Hz-20.2kHz
Gain-
-36dB - +6dB
Q- 16,32,64,128
Subharmonic - -On/Off
Subharmonics % 0-100
24-36Hz Level - 24-36Hz
36-56Hz Level - 36-56Hz
1-3 Zone Controller-
1-3 Output Trims
1-3 Output Trims
4-6 Zone Controller-
4-6
2.10 Navigating the I/O Section
Navigating the Delay Section
Delay - On/Off
Length - Delay Time - Course, Fine
Units - Seconds,Feet,Meters
DELAY
DELAY
From program mode, press the Delay button. Pressing the Data Wheel will select the effect parameter to be edited.
Successive Presses of the Delay button will move you through pre and post crossover delays.
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
AFS On/Off
AFS Clear Mode - Fixed/Live
Type- Speech, Low,Med and High Number of filters 0-12
Number of filters fixed 0-12 Live filter Lift - On/Off
Lift After - 0-60
NEXT PG>
The NEXT and PREV
buttons scroll through
the pages of selected module.
NEXT PG>
The NEXT and PREV
buttons scroll through
the pages of selected module.
Navigating the I/O Section
Input Level 1 -Inf to 20dB
Input Level 2 -Inf to 20dB
Master Level -Inf to 20dB Pink Noise On/Off
Pink Noise Level -10 to 10dB Output Channel 1-6 On/Off
Polarity +/-
Phase -180 to 0
FEEDBACK
I/O Section
From program mode, press the I/O button. Pressing the Data Wheel will select the effect parameter to be edited.
NEXT PG>
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
The NEXT and PREV
buttons scroll through
the pages of selected module.
Navigating the Other Section
Subharmonic Synthesizer OTHER
OTHER
From program mode, press the Other button. Successive presses of the Other button will move you to each of the various insert modules available.
Pressing the Data Wheel will select the effect parameter to be edited.
NEXT PG>
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
The NEXT and PREV
buttons scroll through
the pages of selected module.
Navigating the WIZARD Section
RTA/WIZARD
SYSTEM SETUP
AUTO EQ WIZARD
AFS WIZARD
GEQ Setup-Dual Mono
or Stereo Linked Main Speaker Select-
See list Sub Speaker Select-
See list
Amp Select-
High, Mid, Low
See list Amp Sensitivity-
High, Mid, Low Amp Level
High, Mid, Low Low Amp
Bridged/
Normal-
Load New
Program-
Insert 1 Setup-
Select Insert 2 Setup-
Select
Noise gate-
AGC- Limiter Limiter 4-6
Connect Mic Pink Noise Level
-Inf to 20dB Auto EQ - L Auto EQ - R Auto EQ - L-R
Left and Right when using
Linked Graphic EQ
Select Number of
Fixed Filters
- 0-12 Mixer gain turn
down prompt Select Type -
Low, Med, High mode Mixer Gain Adjust-
WIZARD
From program mode, press the RTA/WIZARD button. Pressing the Data Wheel will select the effect parameter to be edited.
NEXT PG>
Fixed Filter Setup
Done-
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
Navigating the Utility/Meters Section
LCD Contrast 1-16
AEQ Plot - RTA/GEQ
UTILITY
PUP Prog. - Current/Stored
PUP Mute - Current/Stored ZC Panel - 1-6
(Store) - Edit Panel Security Level - Module Select
Security Level- Low, Med, High
260 Device Level-
Low, Med, High Edit High Password
Edit Medium Password Program List Size- 1-10
List Index - 1-10 Program Change mode
Normal/Program
Program Number Lock 1-25
Output Jumpers - 1-6
Setting - 14, 22, 30dB
UTILITY
METERS
From program mode, press the UTILITY button. Pressing the Data Wheel will select the effect parameter to be edited.
Pressing and holding the Utility button will enter you into the meter mennu
Navigating the Subharmonic Synthesizer Section
Subharmonic - -On/Off
Subharmonics % 0-100
24-36Hz Level - 24-36Hz
36-56Hz Level - 36-56Hz
Subharmonic
SUBHARMONIC
From program mode, press the SUBHARMONIC button. Pressing the Data Wheel will select the effect parameter to be edited.
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
Advanced Feedback Suppression (AFS) OTHER
Notch- On - Off
Flatten/Restore
Notch Filter OTHER
Freq 1-6 19.7Hz-20.2kHz
Gain-
-36dB - +6dB
Q- 16,32,64,128
Subharmonic - -On/Off
Subharmonics % 0-100
24-36Hz Level - 24-36Hz
36-56Hz Level - 36-56Hz
1-3 Zone Controller-
1-3 Output Trims
1-3 Output Trims
4-6 Zone Controller-
4-6
Editing Functions
