Driverack – dbx DriveRack 260 User Manual
Page 51
DriveRack
®
43
DriveRack® User Manual
Section 5
Utility
LCD Contrast
10
Auto EQ Plot
RTA
Power Up Modes
PUP Program Stored
PUP Mute
Current
ZC Setup
Panel 1 None
(STORE) - EDIT PANEL
Panel 1
ZC-2
Boost 0dB Cut 0dB
Output
1 3 5
2 4 6
Set Security Level
Pre EQ
Low
Set 260 Device Level
High
Password
Enter Password
Password
Edit High Password
Edit Med Password
Press Store to Change
Press Store
Program List
List Size 10
List Index 1
Program 1
Prog Change Mode
Program List
Prog Lock 24
Output Jumpers
Output 1
Setting 30
Panel 1
ZC-3
Select A
No Change
Panel 1
ZC-4
Switch
No Change
1 2 3 4
- SELECT CHARACTER
NAME:
R
OCK VENUE
- SELECT CHARACTER
NAME:
• Pressing and then rotating the DATA wheel will allow you to first select the latch switch
combination in binary. Pressing the DATA wheel again and rotating it then allows you
to assign this binary switch combination to a program to be loaded. Repeat this process
for all other binary switch combination/program assignments. Press the STORE button to
get back to ZC Setup
• When done, press the PROGRAM/CONFIG button to return to the main Program Screen.
For more information regarding Zone Controllers, including wiring and dip switch settings,
please see section 6.2.
5.1.4 Security
The DriveRack 260 does provide a quick front panel System Lockout feature (see Appendix
A.2 for information on this feature). However, this System Lockout feature requires that the
processor be power cycled to lock/unlock the device. Therefore, the DriveRack 260 also
provides you with an additional password protected security feature to protect all detailed
parameter editing and configuration modification settings of your DriveRack unit. The Utility
menu of the DriveRack system includes a complete security system set-up. This security
system allows you to set security access to unit features including: Program List, Store, Mutes,
Inputs, Pre EQ, Inserts, Pre Delay, Crossover, Post EQ, Dynamics, Post Delay, Outputs, RTA
and Program Lock, with security levels that vary from low to high (low having little or no
access, medium having some access and high having full access). By providing different levels
of access, this ensures limited access to different users. This security system also allows you
to create unique passwords which will limit/prevent any other users from accessing system
parameters. The following information is provided to help you set all security parameters.
Prior to setting security passwords you will access the security menu by pressing the UTILITY
button. Then use the PREV PG or NEXT PG buttons to move to the first page of the security/
password pages of the Utility section. The display will appear as follows:
Utility
LCD Contrast
10
Auto EQ Plot
RTA
Power Up Modes
PUP Program Stored
PUP Mute
Current
ZC Setup
Panel 1 None
(STORE) - EDIT PANEL
Panel 1
ZC-2
Boost 0dB Cut 0dB
Output
1 3 5
2 4 6
Set Security Level
Pre EQ
Low
Set 260 Device Level
High
Password
Enter Password
Password
Edit High Password
Edit Med Password
Press Store to Change
Press Store
Program List
List Size 10
List Index 1
Program 1
Prog Change Mode
Program List
Prog Lock 24
Output Jumpers
Output 1
Setting 30
Panel 1
ZC-3
Select A
No Change
Panel 1
ZC-4
Switch
No Change
1 2 3 4
- SELECT CHARACTER
NAME:
R
OCK VENUE
- SELECT CHARACTER
NAME:
• Note that the arrow indicates the currently selected parameter for editing. To select
parameters to edit from the current page, press the DATA wheel until the arrow is next
to the parameter that you wish to edit.
Utilities/Meters
