• If any ZCs are currently connected and their dip switches properly set, the display will

read ‘Panel Detected’ for any such corresponding Panel (ID) numbers. Rotate the DATA
wheel to select the desired Panel (ID) number (options are 1-6). Once the panel to edit
has been selected, press the STORE button. The display will now give you the option of
selecting one of the following by rotating the DATA wheel:

• ZC-1 (volume boost and cut)
• ZC-2 (volume boost and cut with mute)
• ZC-3 (program change)
• ZC-4 (program change via contact closure)

• If a ZC-1 or ZC-2 is selected, the display will appear something like this:

Utility

LCD Contrast

10

Auto EQ Plot

RTA

Power Up Modes

PUP Program Stored

PUP Mute

Current

ZC Setup

Panel 1 None

(STORE) - EDIT PANEL

Panel 1

ZC-2

Boost 0dB Cut 0dB

Output

1 3 5
2 4 6

Set Security Level

Pre EQ

Low

Set 260 Device Level

High

Password

Enter Password

Password

Edit High Password

Edit Med Password

Press Store to Change

Press Store

Program List

List Size 10

List Index 1

Program 1

Prog Change Mode

Program List

Prog Lock 24

Output Jumpers

Output 1

Setting 30

Panel 1

ZC-3

Select A

No Change

Panel 1

ZC-4

Switch

No Change

1 2 3 4

- SELECT CHARACTER
- LEFT/RIGHT:
-SAVE/-EXIT

NAME:

R

OCK VENUE

- SELECT CHARACTER
- LEFT/RIGHT:
-SAVE/-EXIT

NAME:

• Pressing the DATA wheel will give you the option of setting the range of boost. Pressing

the DATA wheel again will now allow you to set the desired cut range (for full boost/
cut range, set boost to 10 and cut to 40; it is a good idea to then bring down your
crossover gains 10dB in order to make up for this 10dB boost). Once the boost and cut
range has been set, pressing and rotating the DATA wheel will let you select any of the
six outputs to be affected by the programmed level controller. Press the STORE button
to get back to ZC Setup.

• Selecting a ZC-3 gives the ability to assign switches A-D to call up any preset in the 260.

Once a ZC-3 has been selected, the display will appear something like this:

Utility

LCD Contrast

10

Auto EQ Plot

RTA

Power Up Modes

PUP Program Stored

PUP Mute

Current

ZC Setup

Panel 1 None

(STORE) - EDIT PANEL

Panel 1

ZC-2

Boost 0dB Cut 0dB

Output

1 3 5
2 4 6

Set Security Level

Pre EQ

Low

Set 260 Device Level

High

Password

Enter Password

Password

Edit High Password

Edit Med Password

Press Store to Change

Press Store

Program List

List Size 10

List Index 1

Program 1

Prog Change Mode

Program List

Prog Lock 24

Output Jumpers

Output 1

Setting 30

Panel 1

ZC-3

Select A

No Change

Panel 1

ZC-4

Switch

No Change

1 2 3 4

- SELECT CHARACTER
- LEFT/RIGHT:
-SAVE/-EXIT

NAME:

R

OCK VENUE

- SELECT CHARACTER
- LEFT/RIGHT:
-SAVE/-EXIT

NAME:

• Pressing and then rotating the DATA wheel will allow you to first select the desired

position (A-D). These positions correspond to the rotary position labels on the ZC-3.
Once the desired position has been selected, press the DATA wheel again and rotate it
to select which program will be loaded when this selection (A-D) is made on the ZC-3.
Repeat this process for all other switch position/program assignments. Press the STORE
button to get back to ZC Setup

No change means that no program will be loaded for that selection.

• Selecting a ZC-4 gives the ability to load programs using SPDT type switches. Once a

ZC-4 has been selected, the display will appear something like this:
