Page 2 Fact Sheet
Material of Construction
Welded Frame: Painted Carbon Steel
Dilute Piping: PVC
Concentrate Piping: PVC
Flanges:
DIN
DC Drive: IP55
Control Panel: IP55
Control Panel Power: 24VDC
E-Cell Standard Systems
Model GEMK3-15 EU GEMK3-18 EU GEMK3-24 EU GEMK3-27 EU
General Information
Number of Stacks 10 - 15 12 - 18 16 - 24 18 - 27
Type of stack MK-3 MK-3 MK-3 MK-3
Flow Rates
Product Flow Nominal 51.0 m 3 /h 61.2 m 3 /h 81.6 m 3 /h 91.8 m 3 /h
Product Flow Range
34.1-68.1 m 3 /h
150-300 gpm
40.9-81.8 m 3 /h
180-360 gpm
54.5-109.0 m 3 /h
240-480 gpm
61.4-122.6 m 3 /h
270-540 gpm
Concentrate Outlet Flow
(Depends on Recovery & Product
Flow)
3.86-106.29 lpm
0.67-28.08 gpm
3.07-127.56 lpm
0.81-33.70 gpm
4.05-170.08 lpm
1.07-44.93 gpm
4.58-191.35 lpm
1.21-50.55 gpm
Electrode Outlet Flow
19.87 lpm
5.25 gpm
23.85 lpm
6.30 gpm
31.80 lpm
8.40 gpm
35.77 lpm
9.45 gpm
Dimensions
Overall System Dimensions
(Width x Length x Height) 1.5m x 5.3m x 2.1m
60” x 209” x 84”
1.5m x 5.6m x 2.1m
60” x 222” x 84”
1.5m x 6.9m x 2.1m
60” x 270” x 84”
1.5m x 7.2m x 2.1m
60” x 283” x 84”
Inlet Piping DN150 DN150 DN150 DN150
Product Outlet Piping DN150 DN150 DN150 DN150
Rinse Outlet Piping DN150 DN150 DN150 DN150
Electrode Outlet Piping DN25 DN25 DN25 DN25
Concentrate Outlet Piping DN40 DN40 DN40 DN40
All piping sizes are provided for nominal flow rates at 90% recovery.
Shipping Weight
3538 kg
7800 lbs
3855 kg
8500 lbs
4990 kg
11000 lbs
5443 kg
12000 lbs
Electrical
Maximum Output @ 300VDC 78.0 Amps 93.6 Amps 124.8 Amps 140.4 Amps
Connection Requirement 36 kVA 42 kVA 56 kVA 63 kVA
Typical Power Consumption 0.13 – 0.26 kWh/m 3 (0.5 – 1.0 kWh/1000gal )
Standard Options:
1. Premium Model – flow & pressure transmitters, ability to connect to SCADA system.
2. Premium Model Option – removal of PLC & HMI, all wiring terminated at a IP55 Junction Box
Performance, flow rate per stack, recovery and power consumption are all dependent on inlet feed water quality and temperature.
An E-Calc projection must be completed for proper system design & for any performance guarantee to be provided.
