Page 2 FS1620EN
E-Cell Standard Systems
Model GEMK3-1 GEMK3-3 GEMK3-6 GEMK3-9 GEMK3-12
General Information:
Number of Stacks 1 2 - 3 4 - 6 6 – 9 10 - 12
Type of stack MK-3 MK-3 MK-3 MK-3 MK-3
Flow Rates:
Product Flow Nominal 15gpm 45gpm 90gpm 135gpm 180gpm
Range 10-20gpm
2.3-4.5m 3 /h
30-60gpm
6.8-13.6m 3 /h
60-120gpm
13.6-27.3m3/h
90-180gpm
20.4-40.9m3/h
120-240gpm
27.3-54.5m3/h
Concentrate Outlet Flow 0.91-1.5gpm 2.9-4.7gpm 5.8-9.4gpm 8.8-14.1gpm 11.7-18.8gpm
(Depends on Recovery &
Product Flow)
3.4-5.7lpm 11.0-17.8lpm 22.0-35.6lpm 33.3-53.4lpm 44.3-71.2lpm
Electrode Outlet Flow 0.35gpm
1.3lpm
1.05gpm
4.0lpm
2.10gpm
7.9lpm
3.15gpm
11.9lpm
4.2gpm
15.9lpm
Dimensions:
Overall System Dimensions
(Width x Length x Height) 36”x54”x72”
0.9mx1.4mx1.8
m
46”x86”x84”
1.2mx2.2mx2.1
m
46”x107”x84”
1.2mx2.7mx2.1
m
46”x132”x84”
1.2mx3.4mx2.1
m
46”x146”x84”
1.2mx3.7mx2.1
m
Inlet Piping 1” 2” 3” 4” 4”
Product Outlet Piping 1” 2” 3” 4” 4”
Rinse Outlet Piping 1” 2” 3” 4” 4”
Electrode Outlet Piping 0.5” 0.5” 0.5” 0.5” 0.75”
Concentrate Outlet Piping 0.5” 0.5” 0.75” 1” 1.5”
All piping sizes are provided for nominal flow rates at 90% recovery.
Shipping Weight 1000lbs
454kg
2500lbs
1134kg
3500lbs
1588kg
4300lbs
1950kg
5000lbs
2268kg
Electrical:
Maximum Rectifier Output
(@ 300VDC) 5.2Amps 15.6Amps 31.2Amps 46.8Amps 62.4Amps
Connection Requirement 3.5 KVA 8 KVA 15 KVA 22 KVA 29 KVA
Typical Power Consumption 0.5 – 1.0 kWh/1000gal (0.13 – 0.26 kWh/m 3 )
Standard Options:
1. Premium Model – flow & pressure transmitters, ability to connect to SCADA system.
2. Premium Model Option – Allen Bradley Micrologix PLC
3. Premium Model Option – removal of PLC & HMI, all wiring terminated at a NEMA 4 Junction Box
Performance, flow rate per stack, recovery and power consumption are dependent on inlet feed water quality and temperature.
An E-Calc projection must be completed for proper system design & for any performance guarantee to be provided.
Patents Pending.
