Table 2: Materials of Construction

Frame

Painted Carbon Steel

Membrane Elements

Desal AG2521TM or AG2540TM

Membrane Housing

Stainless Steel

Tubing

Polyethylene

Table 3: Pump and Motor

Pump Type

Rotary vane

Motor

1-phase, ODP, 220 VAC


Table 4: E2 Specifications - 50 Hz

Model

E2-0375

E2-0620

E2-1125

E2-1400

E2-2100

ECN
DLX

1226253
1226254

1226256
1226257

1226263
1226264

1226266
1226267

1226271
1226272

Flow Specifications

Recovery Range:
Permeate Rate: m

3

/h (gpm)

Concentrate Rate: m

3

/h (gpm)

33-50%

0.07 (0.3)

0.07-0.04 (0.3-0.2)

33-50%

0.11 (0.5)

0.11-0.07 (0.5-0.3)

33-50%

0.18 (0.78)

0.18-0.12 (0.78-0.5)

33-50%

0.27 (1.2)

0.27-0.18 (1.2-0.8)

33-50%

0.40 (1.8)

0.40-0.27 (1.8-1.2)

Pump and Motor

Pump

Procon Series 2 or 3

Procon Series 4 or 5

Motor: KW (HP)

0.37 (0.5)

0.37 (0.5)

0.56 (0.75)

0.56 (0.75)

0.56 (0.75)

Membrane Elements

Quantity
Array
Element Model

1
1

AG2521TF

2

1-1

AG2521TF

3

1-1-1

AG2521TF

2

1-1

AG2540TF

3

1-1-1

AG2540TF

Connections

Inlet, Permeate, & Concen-
trate: cm (inch)

0.95 (0.38)

0.95 (0.38)

0.95 (0.38)

0.95 (0.38)

0.95 (0.38)

Dimensions & Weights

Height: cm (inch)
Width: cm (inch)
Depth: cm (inch)
Shipping Weight
Estimate: kg (lb)

76 (30)
46 (18)
38 (15)

20 (50)

76 (30)
46 (18)
38 (15)

25 (55)

76 (30)
46 (18)
38 (15)

30 (60)

130 (51)

46 (18)
38 (15)

35 (75)

130 (51)

46 (18)
38 (15)

40 (85)
