Page 2 FS1621EN 0701
E-Cell Standard Systems
Model GEMK3-15 GEMK3-18 GEMK3-24 GEMK3-27
General Information:
Number of Stacks 10 - 15 12 - 18 16 - 24 18 - 27
Type of stack MK-3 MK-3 MK-3 MK-3
Flow Rates:
Product Flow 225 gpm 270 gpm 360 gpm 405 gpm
Nominal Range 150-300 gpm
34.1-68.1 m 3 /h
180-360 gpm
40.9-81.8 m 3 /h
240-480 gpm
54.5-109.0 m 3 /h
270-540 gpm
61.4-122.6 m 3 /h
Concentrate Outlet Flow
(Depends on Recovery &
Product Flow)
0.67-28.08 gpm
3.86-106.29 lpm
0.81-33.70 gpm
3.07-127.56 lpm
1.07-44.93 gpm
4.05-170.08 lpm
1.21-50.55 gpm
4.58-191.35 lpm
Electrode Outlet Flow 5.25 gpm
19.87 lpm
6.30 gpm
23.85 lpm
8.40 gpm
31.80 lpm
9.45 gpm
35.77 lpm
Dimensions:
Overall Dimensions
(Width x Length x Height) 60” x 209” x 84”
1.5m x 5.3m x 2.1m
60” x 222” x 84”
1.5m x 5.6m x 2.1m
60” x 270” x 84”
1.5m x 6.9m x 2.1m
60” x 283” x 84”
1.5m x 7.2m x 2.1m
Inlet Piping 6” 6” 6” 6”
Product Outlet Piping 6” 6” 6” 6”
Rinse Outlet Piping 6” 6” 6” 6”
Electrode Outlet Piping 1” 1” 1” 1”
Concentrate Outlet Piping 1.5” 1.5” 1.5” 1.5”
All piping sizes are provided for nominal flow rates at 90% recovery.
Shipping Weight 7800 lbs
3538 kg
8500 lbs
3855 kg
11000 lbs
4990 kg
12000 lbs
5443 kg
Electrical:
Maximum Output @
300VDC
78.0 Amps 93.6 Amps 124.8 Amps 140.4 Amps
Connection Requirement 36 kVA 42 kVA 56 kVA 63 kVA
Typical Power Consumption: 1 - 2 kWh/1000gal (0.53 – 1.06 kWh/m 3 )
Standard Options:
1. Premium Model – flow & pressure transmitters, ability to connect to SCADA system.
2. Premium Model Option – Allen Bradley Micrologix PLC
3. Premium Model Option – removal of PLC & HMI, all wiring terminated at a NEMA 4 Junction Box
Performance, flow rate per stack, recovery and power consumption are all dependent on inlet feed water quality and temperature.
An E-Calc projection must be completed for proper system design & for any performance guarantee to be provided.
