Fact Sheet
EDI Stacks
Model ...................................................................... GE E-Cell 3X
Stack product flow rate, nominal ........................ 5 m
3
/hr
Performance ..................................................... 16 MOhm-cm
Silica Removal ............................................................. <10 ppb
Cartridge Filtration
Housing model............GE HX-0740-80-V-316-A-EMEA
Housing material ......................... 1.4404 Stainless Steel
Cartridge filter ................................. 1-µ nom, ROSave.Zs*,
RO.Zs01-40XK
PRO E-Cell Models
MODEL
PRO E-Cell EU-10DP
PRO E-Cell EU-20DP
RO Feed Rate:
RO Concentrate Rate:
EDI Product Rate:
EDI Concentrate Rate:
EDI Electrode Rate:
19 m
3
/hr
4.8 m
3
/hr
9-12.4 m
3
/hr
0.6 m
3
/hr
0.2 m
3
/hr
34 m
3
/hr
9.5 m3/hr
18-24.8 m
3
/hr
1.2 m
3
/hr
0.4 m
3
/hr
High pressure pumps
Model:
Manufacturer:
Quantity:
Motor Power and type:
Installed Power:
CRN 20-14 Pass 1
CRN 15-14 Pass 2
Grundfos
2
15kW TEFC Pass 1
11kW TEFC Pass 2
26 KW
CRN 45-7 Pass 1
CRN 45-7 Pass 2
Grundfos
2
30 kW TEFC Pass 1
30 kW TEFC Pass 2
60. KW
Membrane Elements and Housings EDI Stacks
Membrane Quantity:
Memb. Housing Style:
Banking Arrangement:
20 Pass 1 ; 12 Pass 2
4 element long,
4 port
3
2 Pass 1 ; 2
1 Pass 2
36 Pass 1 ; 18 Pass 2
6 element long,
4 port
4
2 Pass 1 ; 2
1 Pass 2
Stack Model :
Stack Quantity:
Power (DC drive, 400 VDC):
GE E-Cell 3X
2
16 A max
GE E-Cell 3X
4
32 A max
Cartridge Filtration
Housing Model:
Housing Quantity:
Cartridge Filter Model:
Cartridge Filter Length:
Cartridge Filter Qty:
HX-0740-80-V-316-A-EMEA
1
ROSave.Zs, RO.Zs01-40XK
40-inch (120 cm)
7
HX-0740-80-V-316-A-EMEA
2
ROSave.Zs, RO.Zs01-40XK
40-inch (102 cm)
14
Installation and Utility Requirements
RO Inlet Connection
EDI Product Outlet
RO1 Reject to Drain
RO2 Product Dump
EDI Product Dump
EDI Concentrate Outlet
EDI Electrode Outlet
Inlet Water Pressure:
Air Pressure:
Drain to be Sized for:
Power:
DN50 Flange PN10
DN40 Flange PN10
DN25 Flange PN10
DN40 Flange PN10
DN40 Flange PN10
DN15 Flange PN10
DN15 Flange PN10
2-4 bar
5.5 barg, oil-free, 90 slpm
22 m3/hr
400VAC, 50hz, 3-Phase
DN80 Flange PN10
DN50 Flange PN10
DN40 Flange PN10
DN50 Flange PN10
DN50 Flange PN10
DN15 Flange PN10
DN15 Flange PN10
2-4 bar
5.5 barg, oil-free, 90 slpm
35 m3/hr
400VAC, 50hz, 3-Phase
Skid Dimensions and Weights (approx.)
Height:
Width:
Length:
Shipping Weight :
Operating Weight:
2.4m
1.4m
5.8m
3,500kg
4,500kg
2.4m
1.6m
7.2m
6,100kg
7,800kg
EDI product flow rate varies with conductivity, hardness/silica, temperature.
