Page 2 Fact Sheet
General Properties
Trailer
Length: 53’-0” (16.2 meters)
Height: 13’-6” (4.1 meters)
Width: 8’-3” (2.5 meters)
Gross operating weight (approx.): 57,000 lbs. (25,9i00 kg)
Gross shipping weight (approx.): 30,700 lbs. (13,900 kg)
Connections
Connection Type: Flange
Raw Water Inlet: 8 inch (200 mm)
Filtrate Outlet: 8 inch (200 mm)
Reject Waste Outlet: 6 inch (150 mm)
Tank Drain Outlet: 6 inch (150 mm)
CIP Waste Outlet: 6 inch (150 mm)
Permeate Tank Drain Outlet: 4 inch (100 mm)
Pressure Relief Outlet: 4 inch (100 mm)
PLC Instrumentation
Parameter Inlet Outlet GE Fanuc PLC
Flow X X Discrete tank level for automat-
ic shut down and control
Pressure X X
Temperature X
Turbidity X X
Electrical
Service: 480 VAC, 3 phase, 60Hz
Full Load Amps 258 A
System on Board
Membrane: GE ZW1500
Pre-Filter: 500 micron, self-cleaning
Max. Water Temp.: 104ºF (40ºC)
Min. Water Temp.: 35ºF (1.7ºC)
Inlet Pressure: 15 psig (1 bar) to 90 psig (6 bar)
Filtrate Outlet Pressure: 30 psig (2 bar)
Reject Waste Outlet
Pressure: Atmosphere (no back pressure)
Tank Drain Outlet Pressure: Gravity
CIP Waste Outlet: <5 psig (<0.35 bar)
Filtrate Tank Drain Outlet: Gravity
Pressure Relief Outlet: 1 psig (0.1 bar) to 100 psig (7 bar)
Air Compressor: 36.5 cfm at 175 psig (12 bar)
Max. Inlet Turbidity: 75 NTU/peak to 200 NTU
Maximum Inlet Water TSS: 300 mg/l
Influent Flow: Up to 1150 US gpm (261 m 3 /hr)
Filtrate Flow: Up to 823 US gpm (186 m 3 /h) continuous
excepting maintenance clean downtime.
Up to 1000 US gpm (227 m
3 /h) averaged
over 24 hours.
Reject Waste Flow: Up to 630 US gpm (143 m 3 /h) max.
intermittent
