GE P&W E-Series Reverse Osmosis - E4 LE 50 Hz - Manual (Page 2)

Page 2 FS1143EN
Table 2: Materials of Construction
Frame Painted Carbon Steel
Membrane Elements AK4040TM
Membrane Housing Stainless Steel
Inlet Plumbing Schedule 80 PVC
High Pressure Plumbing Reinforced rubber hose
Permeate/Concentrate
Tubing
Polyethylene, NSF approved
Control Enclosure NEMA 1
Motor Starters NEMA 4X
Cartridge Filter RO,Save*, 1 micron, 20-inch
Table 3: Pump and Motor
Pump Manufacturer Tonkaflo
Pump Type
Multi-stage, centrifugal
Materials SS shell/housing, Noryl* internals
Castings SS inlet/discharge
Motor 3-phase, TEFC, 190/380 VAC
Table 4: E4-LE Specifications - 50 Hz
Model E4-2200 E4-4400 E4-6600 E4-8800 E4-11000 E4-11000
ECN
DLX 1230853
1230854 1230857
1230858 1230861
1230862 1230865
1230866 1230869
1230870 1230873
1230874
Flow Specifications
Recovery Range:
Permeate Rate:
m
3 /h (gpm)
Concentrate Rate:
m
3 /h (gpm)
50-75%
0.3 (1.5)
0.3-0.1 (1.5-0.5)
50-75%
0.7 (3.0)
0.7-0.2 (3.0-1.0)
50-75%
1.0 (4.5)
1-0.3 (4.5-1.5)
50-75%
1.4 (6)
1.4-0.5 (6.0-2.0)
50-75%
1.7 (7.5)
1.7-0.6 (7.5-2.5)
50-75%
2.1 (9)
2.1-0.7 (9.0-3.0)
Pump and Motor
Pump Model SS1816X SS1816X SS1816X SS1816X SS2812G SS2812G
Motor: KW (HP) 1.5 (2.0) 1.5 (2.0) 1.5 (2.0) 1.5 (2.0) 2.2 (3.0) 2.2 (3.0)
Membrane Elements
Quantity
Array 1
1 2
1-1
3
1-1-1
4
1-1-1-1
5
2-1-1-1
6
2-2-1-1
Connections
Inlet: cm (inch)
Permeate: cm (inch)
Concentrate: cm (inch) 1.9 (0.75)
1.3 (0.5)
1.3 (0.5)
1.9 (0.75)
1.3 (0.5)
1.3 (0.5)
1.9 (0.75)
1.3 (0.5)
1.3 (0.5)
1.9 (0.75)
1.9 (0.75)
1.9 (0.75) 1.9 (0.75)
1.9 (0.75)
1.9 (0.75) 1.9 (0.75)
1.9 (0.75)
1.9 (0.75)
Dimensions & Weights
Height: cm (inch)
Width: cm (inch)
Depth: cm (inch)
Shipping Weight
Estimate: kg (lb) 127 (50)
76 (30)
51 (20)
77 (170)
127 (50)
76 (30)
51 (20)
83 (185)
139 (55)
76 (30)
51 (20)
98 (215)
139 (55)
76 (30)
66 (26)
107 (235)
152 (60)
76 (30)
66 (26)
147 (325)
152 (60)
76 (30)
66 (26)
156 (345)
