E-Series M
Medium Reverse Osmosis Machines, 600 to 2700 liters per hour
Figure 1: E4 M CE Series
When you mention reverse osmosis (RO), GE Water &
Process Technologies is the first name to come to
mind. Our E-series RO machines (Figure 1) are de-
signed for durable operation, high quality product wa-
ter production, easy installation and straightforward
control.
General Properties
Typical Applications
 Process ingredient water
 Safe drinking water
 Boiler feed water
 Ion exchange pre-treatment
Standard Features
 Automatic inlet shut-off valve
 Permeate and Concentrate flow meters
 Pre/post-filter, and primary pressure gauges
 Inlet low pressure switch
 Digital conductivity meter with temperature sensor
 Flow control center including concentrate and recycle
valves
 Microprocessor control panel with one potential free
contact for remote alarm, dosing pump or level con-
trol for permeate tank
Optional Features
 Clean in Place (CIP) system installed on a polypropyl-
ene frame suitable for retrofit.
Table 1: Operating Parameters
Average Operating Pressure 7–15 bars
Maximum Recovery 75%
Nominal Rejection 90-95%
Operating Temperature 5-35  C
Inlet Pressure 3-6 bars
Design Temperature* 15  C
* Varying the operating temperature will affect machine productivity
Table 2: Materials of Construction
Frame Polypropylene frame (E4)
Powder coated steel (E4H)
Membrane Elements AK4040TM
Membrane Housing Fiberglass Reinforced Plastic
Piping PN 16
Cartridge Filter Hytrex*, 5 micron
