GE P&W E-Series Pretreatment - Water Softeners - Manual (Page 2)

Page 2 Fact Sheet
Table 1. Specifications 1
Part Number 2 Brine Tank
Flow
(gpm)
Model
Single Alternating
Connec-
tions
(inches)
Valve
Tank
(inches)
Overall
Height
(inches)
Dimensions
(inches)
Capacity
(lbs)
Min Max BkWsh
Resin
Volume
(ft3)
Capacity
(grains)
S10 3023718 3023719 1 Performa 10 x 52 62 18 x 40 700 2 8 2.5 1.5 45K
S14 3023720 3023721 1 Performa 14 x 65 73 18 x 40 700 5 15 5 3 90K
S21 3023722 3023723 2 Magnum 21 x 62 78 24 x 50 1000 9 30 12 6 180K
S30 3023724 3023725 2 Magnum 30 x 72 83 30 x 50 1500 23 75 25 15 450K
S36 3023726 3023727 2 Magnum 36 x 72 84 39 x 48 2500 30 90 35 20 600K
1 Specifications listed are per individual tank
2 Part numbers listed are for 60 Hz units only
Figure 1. E-Series Water Softener Flow Range
0 10 20 30 40 50 60 70 80 90 100
S10
S14
S21
S30
S36
Flow Rate (gpm)
=1.5-2 or 4-5 gpm/ft 3
=2-4 gpm/ft 3
