FS1263EN

Table 2: Dimensions and Weight

Model²

Dimensions, inches (cm)

Boxed

A

B

1

C

3

Weight

lbs (kg)

AK2540*M

40.0

(101.6)

0.75

(1.9) OD

2.4

(6.1)

5

(2.3)

AK4040C

40.0

(101.6)

0.625

(1.59)

3.9

(9.9)

8

(3.5)

AK4040*M

40.0

(101.6)

0.75

(1.9) OD

3.9

(9.9)

8

(3.5)

AK4040*M WET

40.0

(101.6)

0.75

(1.9) OD

3.9

(9.9)

8

(3.5)

AK8040*, AK8040* 400

40.0

(101.6)

1.125

(2.86)

7.9

(20.1)

32

(14.5)

AK8040*, AK8040* 400 WET

40.0

(101.6)

1.125

(2.86)

7.9

(20.1)

35

(16)

1

Internal diameter unless specified OD (outside diameter).

² These elements are bagged dried, unless specified WET, before shipping.

3

The element diameter (dimension C) is designed for optimum performance in GE

pressure vessels. Others pressure vessel dimension and tolerance may result in
excessive bypass and loss of capacity.

Table 3: Operating and CIP parameters

Typical Operating Pressure

100 psi (689 kPa)

Typical Operating Flux

10-20 GFD (15-35LMH)

Maximum Operating Pressure

400 psi (2,756 kPa)

Maximum Temperature

Continuous operation: 122°F (50°C),
Clean In Place (CIP): 122°F (50°C)

pH Range

Optimum rejection: 7.0-7.5,
Continuous operation: 4.0-11.0,
Clean In Place (CIP): 2.0-11.5

Maximum Pressure Drop

Over an element: 12 psi (83 kPa)
Per housing: 50 psi (345 kPa)

Chlorine Tolerance

1,000+ ppm-hours,
dechlorination recommended

Feedwater

NTU < 1
SDI < 5
