Materials of Construction
High-pressure piping.............................Sch. 10, Duplex 2205
Stainless Steel
Low-pressure piping................................................Sch. 80, PVC
Frame............................................................ Painted carbon steel
Local Enclosure.......................................................FRP, NEMA 4X
Main Enclosure.......................Painted carbon steel, NEMA 4
VFD Enclosure.........................Painted carbon steel, NEMA 4
Clamps/fittings.............................................................Zinc-plated
Membrane Elements and Housings
Style.......................................................... Spiral-wound elements
Membrane type ...........................................TFC HR (Polyamide)
Element Area ........................................................................ 37.2 m
2
Average membrane flux.........................................13.5-17 lmh
Housing material ................................... FRP, 80 Bar (1200 psi)
Housing closure type ..............Ring and plate style closure
Cartridge Filtration
Housing material ................... GRP (glass reinforced plastic)
Cartridge filter ...................... 5-micron nominal, ROsave.Z*s
SeaPRO Models
MODEL
SeaPRO-8
SeaPRO-16
SeaPRO-28
Permeate rate:
Concentrate Rate:
Feed Rate:
100 m
3
/day (18.3 gpm)
185 m
3
/day (33.9 gpm)
285 m
3
/day (52.3 gpm)
200 m
3
/day (36.7 gpm)
371 m
3
/day (68.1 gpm)
571 m
3
/day (104.8gpm)
300 m
3
/day (55.0 gpm)
557 m
3
/day (102.2 gpm)
857 m
3
/day (157.2 gpm)
Pumps and Motors
Model:
Manufacturer:
Quantity:
Motor HP and type:
Design Flow Rate:
Design boost pressure:
MSS 1540
Osmonics/FEDCO
E
1
29.9 kW (40 Hp) TEFC
12 m
3
/hr (52.8 gpm)
47.4 Bar (690 psig)
MSS 2030
Osmonics/FEDCO
E
1
55.9 kW (75 Hp) TEFC
24 m
3
/hr (105.7 gpm)
45.5Bar (660 psig)
MSS 3030
Osmonics/FEDCO
E
1
93.2 kW (125 Hp) TEFC
36 m
3
/hr (158.5 gpm)
42.7 Bar (620 psig)
Energy Recovery Booster
Model:
Manufacturer:
Quantity:
Design boost pressure:
HPB 20
Osmonics/FEDCO
E
1
21.7 Bar (315 psig)
HPB 30
Osmonics/FEDCO
E
1
23.4 Bar (340 psig)
HPB 40
Osmonics/FEDCO
E
1
26.2 Bar (380 psig)
Membrane Elements and Housings
Membranes quantity:
Memb. housing style:
Banking Arrangement:
8
4 element long, 4 port
2, parallel
16
4 element long, 4 port
4, parallel
24
4 element long, 4 port
6, parallel
Cartridge Filtration
Cartridge Filter:
Filter Length:
Filter Quantity:
RO.Zs05-40XK
40” (102 cm)
6 per change out
RO.Zs05-40XK
40” (102 cm)
10 per change out
RO.Zs05-40XK
40” (102 cm)
22 per change out
Installation and Utility Requirements
Inlet:
Permeate:
Concentrate:
Inlet Water Pressure:
Air Pressure:
Drain to be Sized for:
Power:
Control Circuit:
2.0” flange
1.0” flange
1.5” flange
2 Bar, minimum
7 Bar, oil-free
285 m
3
/day (52.3 gpm)
220/380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
3.0” flange
1.5” flange
2.0” flange
2 Bar, minimum
7 Bar, oil-free
571 m
3
/day (104.8gpm)
220/380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
3.0” flange
2.0” flange
3.0” flange
2 Bar, minimum
7 Bar, oil-free
857 m
3
/day (157.2 gpm)
220/380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
SeaPRO Skid
Height:
Width:
Depth:
Weight Estimate for
Shipping Purposes:
224 cm (88”)
132 cm (52”)
506 cm (199”)
1542 kg (3400 lb)
224 cm (88”)
132 cm (52”)
506 cm (199”)
1814 kg (4000 lb)
224 cm (88”)
132 cm (52”)
506 cm (199”)
2041 kg (4500 lb)
