GE P&W Tonkaflo - PROPAK NA Series - Manual (Page 2)

Page 2 AM-FSpwPROPAK-NA_EN
PROPAK NA Models
MODEL PROPAK-100-NA PROPAK-200-NA PROPAK-300-NA
RO Permeate Rate 2 without or with ICR 3 :
RO Concentrate Rate without ICR
RO Concentrate Rate with ICR
UF Feed Rate without ICR:
UF Feed Rate with ICR:
100 gpm (23 m 3 /hr)
33 gpm (7.5 m3/hr)
18 gpm (4 m 3 /hr)
153 gpm (35 m 3 /hr)
141 gpm (32 m 3 /hr)
200 gpm (45 m 3 /hr)
67 gpm (15 m3/hr)
36 gpm (8 m 3 /hr)
307 gpm (70 m 3 /hr)
283 gpm (64 m 3 /hr)
300 gpm (68 m 3 /hr)
100 gpm (23 m 3 /hr)
55 gpm (12.5 m 3 /hr)
460 gpm (104.5 m 3 /hr)
423 gpm (96 m 3 /hr)
Pumps and Motors
RO HP Pump Model:
Manufacturer:
Quantity:
Motor Power and type:
Installed Power:
Design Flow Rate:
Design boost pressure: SS12512KZE
GE/Tonkaflo
1
40 Hp (30 kW) TEFC
30 kW
135 gpm (31 m3/hr)
280 psid (19.3 Bar)
AS40409KTE
GE/Tonkaflo
1
75 Hp (56 kW) TEFC
56 kW
270 gpm (61 m3/hr)
300 psid (20.7 Bar)
AS40409KTE
GE/Tonkaflo
1
75 Hp (56 kW) TEFC
56 kW
405 gpm (92 m3/hr)
245 psid (16.9 Bar)
RO Booster Pump Model:
Manufacturer:
Quantity:
Motor Power and type:
Installed Power:
Design Flow Rate:
Design boost pressure: 4SH2K54C0
Goulds
1
7.5Hp (5.6 kW) TEFC
5.6 kW
135 gpm (31 m3/hr)
47 psid (3.3 Bar)
6SH2M52F0
Goulds
1
15 Hp (11 kW) TEFC
11 kW
270 gpm (61 m3/hr)
54 psid (3.7 Bar)
22SH2Q52F0
Goulds
1
30 Hp (22 kW) TEFC
22 kW
405 gpm (92 m3/hr)
78 psid (5.4 Bar)
UF CIP/Backwash Pump Model:
Manufacturer:
Quantity:
Motor Power and type:
Installed Power:
Design Flow Rate:
Design boost pressure: 4SH2K54C0
Goulds
1
7.5Hp (5.6 kW) TEFC
5.6 kW
135 gpm (31 m3/hr)
47 psid (3.3 Bar)
6SH2M52F0
Goulds
1
15 Hp (11 kW) TEFC
11 kW
270 gpm (61 m3/hr)
54 psid (3.7 Bar)
6SH2N52E0
Goulds
1
20 Hp (15 kW) TEFC
15 kW
390 gpm (89 m3/hr)
50 psid (3.4 Bar)
Membrane Elements and Housings
Maximum UF modules:
9 18 27
RO Membranes Quantity:
RO Membranes Housing Style:
Banking Arrangement: 18 + 6 CR
6 element long, 4 port
2  1 (2  1  1 with ICR)
36 + 6 CR
6 element long, 4 port
4  2 (4  2  1 with ICR)
54 + 12 CR
6 element long, 4 port
6  3 (6  3  2 with ICR)
Cartridge Filtration
Housing Model:
Housing Quantity:
Cartridge Filter Model:
Cartridge Filter Length:
Cartridge Filter Qty: HX-0740-3.0-V-316
1
GX10-40XK
40-inch (120 cm)
7 per housing, 7/change out
HX-0740-3.0-V-316
2
GX10-40XK
40-inch (102 cm)
7 per housing, 14/change out
HX-0750-3.0-V-316
2
GX10-50XK
50-inch (127 cm)
7 per housing, 14/change out
Tank
Tank Size:
Tank Material:
Tank Style:
Tank Height:
Tank Diameter: 500 gallons
HDPE
Dome Top, Cone Bottom
80”
64”
1000 gallons
HDPE
Dome Top, Cone Bottom
117”
64”
1650 gallons
HDPE
Dome Top, Cone Bottom
110”
86”
Installation and Utility Requirements
UF Inlet:
RO Permeate:
RO Permeate ICR:
RO Concentrate:
UF Waste:
Minimum Inlet Water Pressure:
Air Pressure (Actuated Valve Feed):
Aeration:
Drain to be Sized for:
Power:
Control Circuit: 4.0” flange
3.0” flange
1.5” flange
1.5” flange
4.0” flange
10 psig
100 psig
45 ACFM @ 10 psig
200 gpm (45m3/hr)
460-480 VAC, 3-phase, 60Hz
120 VAC, 1-phase, 60Hz
4.0” flange
4.0” flange
2.0” flange
2.0” flange
4..0” flange
10 psig
100 psig
90 ACFM @ 10 psig
400 gpm (90m3/hr)
460-480 VAC, 3-phase, 60Hz
120 VAC, 1-phase, 60Hz
6.0” flange
4.0” flange
2.0” flange
2.0” flange
6.0” flange
10 psig
100 psig
130 ACFM @ 10 psig
600 gpm (136m3/hr)
460-480 VAC, 3-phase, 60Hz
120 VAC, 1-phase, 60Hz
Filtration Skid
Height x Width x Depth inch (cm) 101 x 64 x 274 inch
(258 x 163 x 696 cm)
101x 66 x 276 inch
(258 x 168 x 701 cm)
101 x 76 x 276 inch
(258 x 193 x 701 cm)
Tank Skid
Height x Width x Depth inch (cm) 115x 88 x 149 inch
(293 x 224 x 379 cm)
136.7 x 88 x 154 inch
(347 x 224 x 391 cm)
127 x 96 x 177 inch
(323 x 244 x 449 cm)
2 Maximum permeate rate listed at design temperature within water quality parameters (see PROPAK Water Quality Guidelines for parameters).
3 Standard configuration: ICR Permeate flow returns to the multifunctional tank.
