ISSUED: 09-19-06 SHEET #: 120-9025-4 01-18-11
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870.
2 of 2
Insert three button bumpers (D) into bottom of shelf
clamp bracket (B).
Attach shelf clamp bracket (B) to shelf support
(A) using two 1/4-20 x 20mm screws (F) and two
1/4-20 nuts (G). Repeat steps 1 through 4-1, for
second shelf installation.
NOTE: After both shelves are installed, continue
with installation using the main instruction sheet.
Insert six button bumpers (D) into shelf support
(A). Place glass shelf (C) on shelf support.
C
D
A
D
G
B
F
A
