E
(BOTTOM VIEW)
cross support
cross support
When attaching the cross support to the extension
column, carefully thread retaining collar onto end of
the extension column. Tighten at least four complete
turns ending with one of the small threaded holes
aligned with slot in the end of the extension column.
Insert and tighten one M5 screw (E).
extension
column
retaining
collar
• Set screw (E) is self tapping and may be hard to get
started but is essential to this installation. Failure to
install this screw can cause the mount to fall.
WARNING
