Peerless-AV ACC325 - Installation - Manual (Page 2)

2 of 2 ISSUED: 07-15-09 SHEET #: 120-9068-1
B
A
C
Note: Installation requires an assistant.
Secure shelf (A) to FPZ-600 stand (sold
separately ) using shelf bracket (B) and three M5 x 30 mm phillips screws
(C) at desired position.
Note: Shelf (A) can be flipped over and attached to stand in reverse orientation if desired as shown in detail 1.
C
1
DETAIL 1
A
B
Description Qty. Part #
A shelf 1 104-1069
B shelf bracket 1 104-1070
C M5 x 30 mm phillips screw 3 520-1042
Parts List
A
FPZ-600
(sold
separately )
