Technical Specification
Technical Specification
Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE802.3x Flow Control and Back Pressure
IEEE802.3af Power over Ethernet
Protocol CSMA/CD
Transfer Rate
14,880 pps for 10Base-T Ethernet port
148,800 pps for 100Base-TX Fast Ethernet port
MAC Address 2K MAC address table
Connector
10/100TX: 5 x RJ-45 with auto MDI/MDI-X function;
Supports 4 PoE injector function
PoE Pin Assignment
RJ-45 port #1 ~ # 4 support IEEE 802.3af End-point,
Alternative A mode.
Positive (VCC+): RJ-45 pin 1, 2.
Negative (VCC-): RJ-45 pin 3, 6.
Data (1,2,3,6 )
LED
Per unit: Power 1 (Green), Power 2 (Green), Fault(Red)
Per port: Link/Activity (Green), Full duplex/Collision (Yellow)
PoE: Feeding Power (Green)
