Network Application
Hardware Installation
Installation Steps
1. Unpack the switch.
2. Check that the DIN rail is screwed onto the switch. If the DIN rail clip is not screwed
onto the switch. Please refer to DIN-Rail Mounting section for DIN-Rail installation. If
you want to wall or panel mount the switch, then please refer to Wall or Panel Mount
Plate Mounting.
3. Apply power to the switch. If you need help with this please refer to the Wiring the
Power Inputs section. The power LED on the switch will light up. Please refer to the
LED Indicators section for meaning of LED lights.
4. Prepare the twisted-pair, Ethernet cable for connection.
5. Insert one side of cable into one of the switches Ethernet ports and the other side of the
cable to the network device you want connected ex: switch, PC or Server. The port LED
on the Industrial switch will light up when the cable is connected to the network device.
Please refer to the LED Indicators section for LED light meaning.
6. When all connections are made and the LED lights show normal activity the installation
is complete.
