CS5.241, CS5.241-C1, CS5.241-S1
C–Series
24V, 5A, S INGLE P HASE I NPUT
Dec. 2006 / Rev. 1.3 DS-CS5.241-EN
All parameters are specified at 24V, 5A, 230Vac, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone +49 89 9278 0 Germany
9/20
14. EMC
The CE mark is in conformance with EMC guideline 89/336/EEC and 93/68/EEC and the low-voltage directive (LVD)
73/23/EWG. A detailed EMC Report is available on request.
EMC Immunity EN 61000-6-2 EN 61000-6-1 Generic standards
Electrostatic discharge EN 61000-4-2 Contact discharge
Air discharge 8kV
15kV Criterion A
Criterion A
Electromagnetic RF field EN 61000-4-3 80MHz-1GHz 10V/m Criterion A
Fast transients (Burst) EN 61000-4-4 Input lines
Output lines 4kV
2kV Criterion A
Criterion A
Surge voltage on input EN 61000-4-5 L Æ N
N / L Æ PE 2kV
4kV Criterion A
Criterion A
Surge voltage on output EN 61000-4-5 + Ж -
+ / - Ж PE 500V
500V Criterion A
Criterion A
Conducted disturbance EN 61000-4-6 0,15-80MHz 10V Criterion A
Mains voltage dips EN 61000-4-11 0% of 100Vac
40% of 100Vac
70% of 100Vac
0% of 200Vac
40% of 200Vac
70% of 200Vac
0Vac, 20ms
40Vac, 200ms
70Vac, 500ms
0Vac, 20ms
80Vac, 200ms
140Vac, 500ms Criterion A
Criterion C
Criterion A
Criterion A
Criterion C
Criterion A
Voltage interruptions EN 61000-4-11 0Vac, 5000ms Criterion C
Input voltage swells PULS internal standard 300Vac, 500ms Criterion A
Powerful transients VDE 0160 over entire load
range
750V, 1.3ms Criterion A
Criterions:
A: Power supply shows normal operation behavior within the defined limits.
C: Temporary loss of function is possible. Power supply might shut-down and restarts by itself. No damages or hazards for the
power supply occur.
Switching frequency 175kHz to 225kHz input voltage dependent 24V, 2.5A
100kHz to 130kHz input voltage dependent 24V, 5A
