Technical Specification
Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX/FX
IEEE802.3ab 1000Base-T
IEEE802.3z Gigabit fiber
IEEE802.3x Flow Control and Back Pressure
IEEE802.3af Power over Ethernet
Protocol CSMA/CD
Transfer Rate
14,880 pps for 10Base-T Ethernet port
148,800 pps for 100Base-TX/FX Fast Ethernet port
1,488,000 pps for Gigabit Fiber Ethernet port
Packet Buffer 1Mbits
MAC address 8K MAC address table
LED
8 ports 10/100TX : Link/Activity (Green), Full duplex/Collision
(Yellow), Power Feeding (Green)
Giga port: Link/Activity (Green)
Per unit: Power 1 (Green), Power 2 (Green), Fault (Red)
Network Cable
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5, 5e cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5/5E cable
EIA/TIA-568 100-ohm (100m)
1000Base-TX: 2-pair UTP/STP Cat. 5E cable
EIA/TIA-568 100-ohm (100m)
Optical cable
Distance:
Multi mode:
0 to 5 km, 1300 nm (50/125 μm, 800 MHz*km)
0 to 4 km, 1300 nm (62.5/125
μm, 500 MHz*km)
Single mode:
0 to 40 km, 1310 nm (9/125 μm, 3.5 PS/(nm*km))
0 to 80 km, 1550 nm (9/125 μm, 19 PS/(nm*km))
