Page 9
-0.5
-0.2
-0.3
-0.4
-0.1
0
0.1
0.2
0.3
0.4
0.5
DIFFERENTIAL NONLINEARITY
vs. OUTPUT
(LOW-FREQUENCY SERVO-LOOP DATA)
MAX106 toc27
OUTPUT CODE
DNL (LSB)
0
32
64
96
128 160 192 224 256
MAX106
±5V, 600Msps, 8-Bit ADC with On-Chip
2.2GHz Bandwidth Track/Hold Amplifier
_______________________________________________________________________________________
9
Pin Description
DREADY
200mV/div
DATA
200mV/div
DREADY RISE/FALL TIME,
DATA RISE/FALL TIME
MAX106 toc28
500ps/div
1.0
1.1
1.2
1.3
1.4
1.5
0
1000
500
1500
2000
2500
VOLTAGE STANDING-WAVE RATIO
vs. ANALOG INPUT FREQUENCY
MAX106 toc29
ANALOG INPUT FREQUENCY (MHz)
VSWR
Test Point. Do not connect.
TESTPOINT
(T.P.)
A10, E17, F2, P3, R17, R18
Digital Ground
GNDD
A11, B11, B16, B17, C11, C16, U9, U17,
V9, V17, V18, W9
PECL Supply Voltage, +3V to +5V
V
CC
O
A12–A19, B19, C19, D19, E19, F19, G19,
H19, J19, K19, L19, M19, N19, P19, T19,
U19, V19, W10–W19
Analog Supply Voltage, +5V. Supplies analog comparator array.
V
CC
A
A9, B9, C9, U7, V7, W7
Analog Ground—For comparator array.
GNDA
A8, B8, C8, U6, V6, W6
CONTACT
Analog Supply Voltage, +5V. Supplies T/H amplifier, clock distribu-
tion, bandgap reference, and reference amplifier.
V
CC
I
A5, B5, C5, H2, H3, M2, M3, U5, V5, W5
Analog Ground—for T/H amplifier, clock distribution, bandgap refer-
ence, and reference amplifier.
GNDI
A1–A4, A6, A7, B1, B2, C1, C2, D1, D2,
D3, G1, H1, J2, J3, K1, K2, K3, L2, L3,
M1, N1, T2, T3, U1, V1, V2, W1–W4
FUNCTION
NAME
Typical Operating Characteristics (continued)
(V
CC
A = V
CC
I = V
CC
D = +5.0V, V
EE
= -5.0V, V
CC
O = +3.3V, REFIN connected to REFOUT, f
S
= 600Msps, T
A
= +25°C, unless other-
wise noted.)
