MAX106
±5V, 600Msps, 8-Bit ADC with On-Chip
2.2GHz Bandwidth Track/Hold Amplifier
_______________________________________________________________________________________ 3
DC ELECTRICAL CHARACTERISTICS (continued)
(V
CC
A = V
CC
I = V
CC
D = +5.0V ±5%, V
EE
= -5.0V ±5%, V
CC
O = +3.0V to V
CC
D, REFIN connected to REFOUT, T
A
= T
MIN
to T
MAX
,
unless otherwise noted. Typical values are at T A = +25°C.)
CLK+ and CLK- to CLKCOM, T A = +25°C
CONDITIONS
ppm/°C 150 TC R
Input Resistance Temperature
Coefficient
Ω 48 50 52 R CLK Clock Input Resistance
UNITS MIN TYP MAX SYMBOL PARAMETER
(Note 10)
(Note 9)
VIN+ = VIN- = ±0.1V
V IH = 2.4V
V IL = 0
dB 40 68 PSRR-
Negative Power-Supply
Rejection Ratio (Note 8)
dB 40 73 PSRR+
Positive Power-Supply Rejection
Ratio (Note 8)
dB 40 68 CMRR
Common-Mode Rejection Ratio
(Note 7)
W 5.25 P
DISS
Power Dissipation (Note 6)
Output Supply Current (Note 6) mA 75 115 I CC O
mA 205 340 I CC D Digital Supply Current
mA -290 -210 I
EE
Negative Input Supply Current
mA 108 150 I CCI Positive Input Supply Current
mA 480 780 I CCA Positive Analog Supply Current
V 0.8 V IL Low-Level Input Voltage
V 2.0 V IH High-Level Input Voltage
V -1.810 -1.620 V OL Digital Output Low Voltage
V -1.025 -0.880 V OH Digital Output High Voltage
V -1.475 V IL Digital Input Low Voltage
µA 50 I IH High-Level Input Current
µA -1 1 I IL Low-Level Input Current
V -1.165 V IH Digital Input High Voltage
CLOCK INPUTS (Note 3)
TTL/CMOS CONTROL INPUTS (DEMUXEN, DIVSELECT)
DEMUX RESET INPUT (Note 4)
PECL DIGITAL OUTPUTS (Note 5)
POWER REQUIREMENTS
