MAX106
±5V, 600Msps, 8-Bit ADC with On-Chip
2.2GHz Bandwidth Track/Hold Amplifier
10 ______________________________________________________________________________________
Pin Description (continued)
CONTACT
Analog Supply Voltage, -5V. Supplies T/H amplifier, clock distribu-
tion, bandgap reference, and reference amplifier.
V EE
B3, B4, C3, C4, E3, F3, G2, G3, N2, N3,
U2, U3, U4, V3, V4
FUNCTION NAME
Reference Ground. Must be connected to GNDI. GNDR B6, B7
Primary Output Data Bit 0 (LSB) P0+ B12
Digital Supply Voltage, +5V V CC D
B10, B18, C10, C17, C18, T17, T18, U8,
U18, V8, W8
Primary Output Data Bit 1 P1+ B14
Reference Input REFIN C6
Auxiliary Output Data Bit 1 A1+ B15
Auxiliary Output Data Bit 0 (LSB) A0+ B13
Complementary Primary Output Data Bit 0 (LSB) P0- C12
Complementary Primary Output Data Bit 1 P1- C14
Complementary Auxiliary Output Data Bit 0 (LSB) A0- C13
TTL/CMOS Demux Divide-Selection Input
1: Decimation DIV4 mode
0: Demultiplexed DIV2 mode
DIVSELECT D17
Die Temperature Measurement Test Point. See Die Temperature
Measurement section.
ICONST E1
Tie to V CC O to power the auxiliary port. Tie to GNDD to power
down.
AUXEN2 D18
Complementary Auxiliary Output Data Bit 1 A1- C15
Reference Output REFOUT C7
Die Temperature Measurement Test Point. See Die Temperature
Measurement section.
IPTAT E2
Offset Adjust Input VOSADJ F1
TTL/CMOS Demux Enable Control
1: Enable Demux
0: Disable Demux
DEMUXEN E18
Primary Output Data Bit 2 P2+ F18
Auxiliary Output Data Bit 2 A2+ G18
Complementary Auxiliary Output Data Bit 2 A2- G17
Complementary Primary Output Data Bit 2 P2- F17
Complementary Primary Output Data Bit 3 P3- H17
Primary Output Data Bit 3 P3+ H18
