MAX106
±5V, 600Msps, 8-Bit ADC with On-Chip
2.2GHz Bandwidth Track/Hold Amplifier
______________________________________________________________________________________
11
Pin Description (continued)
Differential Input Voltage (-)
VIN-
J1
Auxiliary Output Data Bit 3
A3+
J18
Primary Output Data Bit 4
P4+
L18
Complementary Primary Output Data Bit 4
P4-
L17
Complementary Auxiliary Output Data Bit 3
A3-
J17
Auxiliary Output Data Bit 4
A4+
M18
Primary Output Data Bit 5
P5+
N18
Complementary Primary Output Data Bit 5
P5-
N17
CONTACT
Complementary Auxiliary Output Data Bit 5
A5-
P17
FUNCTION
NAME
This contact must be connected to GNDI.
TESTPOINT
(T.P.)
P2
Complementary Sampling Clock Input
CLK-
P1
Complementary Auxiliary Output Data Bit 4
A4-
M17
Auxiliary Output Data Bit 5
A5+
P18
50
Ω Clock Termination Return
CLKCOM
R1, R2, R3
Sampling Clock Input
CLK+
T1
Complementary PECL Reset Output
RSTOUT-
U11
Complementary PECL Demux Reset Input
RSTIN-
U10
Tie to V
CC
O to power the auxiliary port. Tie to GNDD to power
down.
AUXEN1
R19
Complementary PECL Overrange Bit
OR-
U12
Complementary Primary Output Data Bit 7 (MSB)
P7-
U14
Complementary Primary Output Data Bit 6
P6-
U16
Complementary Auxiliary Output Data Bit 6
A6-
U15
Complementary Auxiliary Output Data Bit 7 (MSB)
A7-
U13
PECL Reset Output
RSTOUT+
V11
PECL Demux Reset Input
RSTIN+
V10
PECL Overrange Bit
OR+
V12
Primary Output Data Bit 7 (MSB)
P7+
V14
Primary Output Data Bit 6
P6+
V16
Auxiliary Output Data Bit 6
A6+
V15
Auxiliary Output Data Bit 7 (MSB)
A7+
V13
Complementary Data-Ready Clock
DREADY-
K17
Differential Input Voltage (+)
VIN+
L1
Data-Ready Clock
DREADY+
K18
