MAX2063
Dual 50MHz to 1000MHz High-Linearity,
Serial/Parallel-Controlled Digital VGA
20
Table 7. Typical Application Circuit Component Values
DESIGNATION QTY DECRIPTION COMPONENT SUPPLIER
C1, C2, C6, C8,
C9, C13
6
1000pF capacitors (0402)
Murata GRM1555C1H102J
Murata North America Electronics, Inc.
C4, C7, C11,
C14, C16
5
10nF capacitors (0402)
Murata GRM155R71E103K
Murata North America Electronics, Inc.
C15 1
1 mF capacitor (0603)
Murata GRM188R71C105K
Murata North America Electronics, Inc.
L1, L2 2
820nH inductors (1008)
Coilcraft 1008CS-821XJLC
Coilcraft, Inc.
U1 1
VGA (48-pin thin QFN-EP, 7mm x 7mm)
Maxim MAX2063ETM+
Maxim Integrated Products, Inc.
