Typical operating characteristics (continued) – Rainbow Electronics MAX510 User Manual
Page 7
MAX509/MAX510
Quad, Serial 8-Bit DACs
with Rail-to-Rail Outputs
_______________________________________________________________________________________
7
5V
100mV
1µS
A = DIGITAL INPUT, 5V/div
B = OUT_ , 2V/div
TIMEBASE = 1
µ
s/div
V
DD
= +5V
REF_ = +4V
ALL BITS OFF TO ALL BITS ON
R
L
= 10k
Ω
, C
L
= 100pF
POSITIVE SETTLING TIME
(V
SS
= AGND OR -5V)
A
B
5V
100mV
1µS
A = DIGITAL INPUT, 5V/div
B = OUT_ , 2V/div
TIMEBASE = 1
µ
s/div
V
DD
= +5V
REF_ = +4V
ALL BITS ON TO ALL BITS OFF
R
L
= 10k
Ω
, C
L
= 100pF
NEGATIVE SETTLING TIME
(V
SS
= AGND)
A
B
____________________________Typical Operating Characteristics (continued)
(T
A
= +25°C, unless otherwise noted.)
A = SCLK, 333kHz
B = OUT_, 10mV/div
TIMEBASE = 2
µ
s/div
CLOCK FEEDTHROUGH
A
B
5V
100mV
1µS
A = DIGITAL INPUT, 5V/div
B = OUT_ , 2V/div
TIMEBASE = 1
µ
s/div
V
DD
= +5V
REF_ = +4V
ALL BITS ON TO ALL BITS OFF
R
L
= 10k
Ω
, C
L
= 100pF
NEGATIVE SETTLING TIME
(V
SS
= -5V)
A
B
