MAX509/MAX510
Quad, Serial 8-DACs
with Rail-to-Rail Outputs
6 _______________________________________________________________________________________
____________________________Typical Operating Characteristics (continued)
(T A = +25°C, unless otherwise noted.)
A = REFA, 10V p-p
B = OUTA, 100 µ V/div, UNLOADED
TIMEBASE = 10 µ s/div
V DD = +5V, V SS = -5V
CODE = ALL 0s
REFERENCE FEEDTHROUGH AT 40kHz
A
B
A = REFA, 10V p-p
B = OUTA, 50 µ V/div, UNLOADED
TIMEBASE = 1ms/div
REFERENCE FEEDTHROUGH AT 400Hz
A
B
A = REFA, 10V p-p
B = OUTA, 50 µ V/div, UNLOADED
TIMEBASE = 50 µ s/div
REFERENCE FEEDTHROUGH AT 10kHz
A
B
5V 50µV
100µS
A = REFA, 10V p-p
B = OUTA, 50 µ V/div, UNLOADED
TIMEBASE = 100 µ s/div
REFERENCE FEEDTHROUGH AT 4kHz
A
B 10
5.0
3.6
0 -4
ZERO-CODE ERROR
vs. NEGATIVE SUPPLY VOLTAGE
3.8
4.8
MAX509-FG09
V SS (V)
ZERO-CODE ERROR (mV)
-3
4.4
4.0
-1 -2
4.6
3.4
4.2
-5 -6
V DD = +5V
VREF = +4V
A = CS, 2V/div
B = OUTA, 20mV ˜
TIMEBASE = 200ns/div
WORST-CASE 1LSB DIGITAL STEP CHANGE
A
B
200nS
2V 20mV
