DS1859
Dual, Temperature-Controlled Resistors with
Internally Calibrated Monitors
16 ____________________________________________________________________
MEMORY
LOCATION
(hex)
EEPROM/
SRAM
R/W
DEFAULT
SETTING
(hex)
NAME OF LOCATION FUNCTION
4 — R/W 0 MON2U
This bit goes high after a MON2 update has
occurred for the corresponding measurement
in bytes 66h to 67h. This bit can be written to
a 0 by the user and monitored to verify that a
conversion has occurred.
3 — — 0 MON3U
This bit goes high after a MON3 update has
occurred for the corresponding measurement
in bytes 68h to 69h. This bit can be written to
a 0 by the user and monitored to verify that a
conversion has occurred.
2 — — 0 — —
1 — — 0 — —
0 — — 0 — —
70 SRAM R Alarm flags —
Bit 7 — — — TMPhi
This alarm flag goes high when the upper limit
of the temperature setting is violated.
6 — — — TMPlo
This alarm flag goes high when the lower limit
of the temperature setting is violated.
5 — — — V CC hi
This alarm flag goes high when the upper limit
of the V
CC setting is violated.
4 — — — V CC lo
This alarm flag goes high when the lower limit
of the V
CC setting is violated.
3 — — — MON1hi
This alarm flag goes high when the upper limit
of the MON1 setting is violated.
2 — — — MON1lo
This alarm flag goes high when the lower limit
of the MON1 setting is violated.
1 — — — MON2hi
This alarm flag goes high when the upper limit
of the MON2 setting is violated.
0 — — — MON2lo
This alarm flag goes high when the lower limit
of the MON2 setting is violated.
71 SRAM R — Alarm flags —
Bit 7 — — — MON3hi
This alarm flag goes high when the upper limit
of the MON3 setting is violated.
6 — — — MON3lo
This alarm flag goes high when the lower limit
of the MON3 setting is violated.
5 — — — X —
4 — — — X —
Main Device (continued)
