15
Packaging Information
AT24C1024
1471D–07/01
2.85 (0.112)
8
7
6
5 4
3
2
1
3.84 (0.151)
0.75 (0.029)
0.80 (0.031)
0.75 (0.029) 1.05 (0.041) 0.38 (0.015)
0.90 (0.035)
TOP VIEW
BOTTOM VIEW
SIDE VIEW
8U8, 8-ball, die Ball Grid Array Package (dBGA)
Dimensions in Millimeters and (Inches)
