AT27BV020
4
Notes: 1. V
CC
must be applied simultaneously with or before V
PP
, and removed simultaneously with or after V
PP
.
2. V
PP
may be connected directly to V
CC
, expect during programming. The supply current would then be the sum of I
CC
and I
PP
.
DC and AC Operating Conditions for Read Operation
AT27BV020-90 AT27BV020-12 AT27BV020-15
Operating Temperature
(Case)
Com. 0°C - 70°C 0°C - 70°C 0°C - 70°C
Ind. -40°C - 85°C -40°C - 85°C -40°C - 85°C
V
CC
Power Supply
2.7V to 3.6V 2.7V to 3.6V 2.7V to 3.6V
5V ± 10% 5V ± 10% 5V ± 10%
DC and Operating Characteristics for Read Operation
Symbol Parameter Condition Min Max Units
V
CC
= 2.7V to 3.6V
I
LI
Input Load Current V
IN
= 0V to V
CC
±1 µA
I
LO
Output Leakage Current V
OUT
= 0V to V
CC
±5 µA
I
PP1
(2) V
PP
(1) Read/Standby Current V
PP
= V
CC
10 µA
I
SB
V
CC
(1) Standby Current
I
SB1
(CMOS), CE = V
CC =
± 0.3V 20 µA
I
SB2
(TTL), CE = 2.0 to V
CC
+ 0.5V 100 µA
I
CC
V
CC
Active Current f = 5 MHz, I
OUT
= 0 mA, CE = V
IL
, V
CC
= 3.6V 8 mA
V
IL
Input Low Voltage
V
CC
= 3.0 to 3.6V -0.6 0.8 V
V
CC
= 2.7 to 3.6V -0.6 0.2 x V
CC
V
V
IH
Input High Voltage
V
CC
= 3.0 to 3.6V 2.0 V
CC
+ 0.5 V
V
CC
= 2.7 to 3.6V 0.7 x V
CC
V
CC
+ 0.5 V
V
OL
Output Low Voltage
I
OL
= 2.0 mA 0.4 V
I
OL
= 100 µA 0.2 V
I
OL
= 20 µA 0.1 V
V
OH
Output High Voltage
I
OH
= -2.0 =mA 2.4 V
I
OH
= -100 µA V
CC
- 0.2 V
I
OH
= -20 µA V
CC
- 0.1 V
V
CC
= 4.5V to 5.5V
I
LI
Input Load Current V
IN
= 0V to V
CC
±1 µA
I
LO
Output Leakage Current V
OUT
= 0V to V
CC
±5 µA
I
PP1
(2) V
PP
(1) Read/Standby Current V
PP
= V
CC
10 µA
I
SB
V
CC
(1) Standby Current
I
SB1
(CMOS), CE = V
CC
± 0.3V 100 µA
I
SB2
(TTL), CE = 2.0 to V
CC
+ 0.5V 1 mA
I
CC
V
CC
Active Current f = 5 MHz, I
OUT
= 0 mA, CE = V
IL
25 mA
V
IL
Input Low Voltage -0.6 0.8 V
V
IH
Input High Voltage 2.0 V
CC
+ 0.5 V
V
OL
Output Low Voltage I
OL
= 2.1 mA 0.4 V
V
OH
Output High Voltage I
OH
= -400 µA 2.4 V
