AT25010A/020A/040A [Preliminary]
3402A–SEEPR–10/3/03
Note: 1. This parameter is characterized and is not 100% tested.
Notes: 1. This parameter is preliminary and Atmel may change the specifications upon further characterization.
2. V
IL
min and V
IH
max are reference only and are not tested.
Pin Capacitance
(1)
Applicable over recommended operating range from T
A
= 25°C, f = 1.0 MHz, V
CC
= +5.0V (unless otherwise noted).
Symbol Test Conditions Max Units Conditions
C
OUT
Output Capacitance (SO) 8 pF V
OUT
= 0V
C
IN
Input Capacitance (CS, SCK, SI, WP, HOLD) 6 pF V
IN
= 0V
DC Characteristics
Applicable over recommended operating range from: T
A
= -40°C to +125°C, V
CC
= +2.7V to +5.5V.
Symbol Parameter Test Condition Min Max Units
V
CC1
Supply Voltage 2.7 5.5 V
V
CC2
Supply Voltage 4.5 5.5 V
I
CC1
Supply Current V
CC
= 5.0V at 1 MHz, SO = Open, Read 3.0 mA
I
CC2
Supply Current
V
CC
= 5.0V at 2 MHz, SO = Open,
Read, Write
6.0 mA
I
SB1
Standby Current V
CC
= 2.7V CS = V
CC
5 µA
I
SB2
Standby Current V
CC
= 5.0V CS = V
CC
10 µA
I
IL
Input Leakage V
IN
= 0V to V
CC
-0.6 3.0 µA
I
OL
Output Leakage V
IN
= 0V to V
CC
-0.6 3.0 µA
V
IL
(2) Input Low Voltage -0.6 V
CC
x 0.3 V
V
IH
(2) Input High Voltage V
CC
x 0.7 V
CC
+ 0.5 V
V
OL1
Output Low Voltage
4.5V
≤
V
CC
≤
5.5V
I
OL
= 2.0 mA 0.4 V
V
OH1
Output High Voltage I
OH
= -1.0 mA V
CC
- 0.8 V
V
OL2
Output Low Voltage
2.7V
≤
V
CC
≤
5.5V
I
OL
= 0.15 mA 0.2 V
V
OH2
Output High Voltage I
OH
= -100 µA V
CC
- 0.2 V
