3

AT24C164

0105F–SEEPR–08/02

Pin Description

SERIAL CLOCK (SCL): The SCL input is used to positive edge clock data into each
EEPROM device and negative edge clock data out of each device.

SERIAL DATA (SDA): The SDA pin is bidirectional for serial data transfer. This pin is
open-drain driven and may be wire-ORed with any number of other open-drain or open
collector devices.

DEVICE SELECT (A2, A1, A0): The A2, A1 and A0 pins are device address inputs that
may be hardwired or actively driven to V

DD

or V

SS

. These inputs allow the selection for

one of eight possible devices sharing a common bus. The AT24C164 can be made
compatible with the AT24C16 by tying A2, A1 and A0 to V

SS

. Device addressing is dis-

cussed in detail in the device addressing section.

WRITE PROTECT (WP): The write protect input, when tied low to GND, allows normal
write operations.

Memory Organization

The AT24C164 is internally organized with 256 pages of 8 bytes each. Random word
addressing requires an 11 bit data word address.
