AT27C516
6
Input Test Waveforms and
Measurement Levels Output Test Load
Note: 1. Typical values for nominal supply voltage. This parameter is only sampled and is not 100% tested.
t
R
, t
F
< 5 ns (10% to 90%)
For -45, -55, and -70 devices only:
t
R
, t
F
< 20 ns (10% to 90%)
For -85 and -10 devices only:
Note: C
L
= 100 pF including jig
capacitance, except -45,
-55, and -70 devices,
where C
L
= 30 pF.
Pin Capacitance
f = 1 MHz, T = 25°C (1)
Symbol Typ Max Units Conditions
C
IN
4 10 pF V
IN
= 0V
C
OUT
8 12 pF V
OUT
= 0V
