DS1249Y/AB
021497 8/9
DC TEST CONDITIONS
Outputs Open
Cycle = 200 ns for operating current
All voltages are referenced to ground
AC TEST CONDITIONS
Output Load: 100 pF + 1TTL Gate
Input Pulse Levels: 0V to 3.0V
Timing Measurement Reference Levels
Input: 1.5V
Output: 1.5V
Input pulse Rise and Fall Times: 5 ns
ORDERING INFORMATION
DS1249 TTP– SSS – III
Operating Temperature Range
blank: 0
° to 70 °
IND: –40 ° to 85 ° C
Access
70:
100: Speed
70 ns
100 ns
Package
blank: 32–pin 600 mil DIP
V
CC
Tolerance
Y: ± 10%
AB: ± 5%
