AT28C16
4
Notes: 1. X can be V
IL
or V
IH
.
2. Refer to AC Programming Waveforms.
3. V
H
= 12.0V
±
0.5V
DC and AC Operating Range
AT28C16-15
Operating
Temperature (Case)
Com. 0°C - 70°C
Ind. -40°C - 85°C
V
CC
Power Supply 5V
±
10%
Operating Modes
Mode CE OE WE I/O
Read V
IL
V
IL
V
IH
D
OUT
Write (2) V
IL
V
IH
V
IL
D
IN
Standby/Write Inhibit V
IH
X (1) X High Z
Write Inhibit X X V
IH
Write Inhibit X V
IL
X
Output Disable X V
IH
X High Z
Chip Erase V
IL
V
H
(3) V
IL
High Z
DC Characteristics
Symbol Parameter Condition Min Max Units
I
LI
Input Load Current V
IN
= 0V to V
CC
+ 1V 10
µ
A
I
LO
Output Leakage Current V
I/O
= 0V to V
CC
10
µ
A
I
SB1
V
CC
Standby Current CMOS CE = V
CC
- 0.3V to V
CC
+ 1.0V 100
µ
A
I
SB2
V
CC
Standby Current TTL CE = 2.0V to V
CC
+ 1.0V
Com. 2 mA
Ind. 3 mA
I
CC
V
CC
Active Current AC
f = 5 MHz; I
OUT
= 0 mA
CE = V
IL
Com. 30 mA
Ind. 45 mA
V
IL
Input Low Voltage 0.8 V
V
IH
Input High Voltage 2.0 V
V
OL
Output Low Voltage I
OL
= 2.1 mA .4 V
V
OH
Output High Voltage I
OH
= -400
µ
A 2.4 V
