DS1220AB/AD
100495 3/10
4
ABSOLUTE MAXIMUM RATINGS*
Voltage on Any Pin Relative to Ground -0.3V to +7.0V
Operating Temperature 0 ° C to 70 ° C; -40 ° C to +85 ° C for IND parts
Storage Temperature -40 ° C to +70 ° C; -40 ° C to +85 ° C for IND parts
Soldering Temperature 260 ° C for 10 seconds
* This is a stress rating only and functional operation of the device at these or any other conditions above those
indicated in the operation sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods of time may affect reliability.
RECOMMENDED DC OPERATING CONDITIONS (t
A:
See Note 10)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
DS1220AB Power Supply Voltage V
CC
4.75 5.0 5.25 V
DS1220AD Power Supply Voltage V
CC
4.50 5.0 5.50 V
Logic 1 V
IH
2.2 V
CC
V
Logic 0 V
IL
0.0 +0.8 V
(V
CC
=5V + 10% for DS1220AD)
DC ELECTRICAL CHARACTERISTICS (t
A:
See Note 10) (V
CC
=5V + 5% for DS1220AB)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Leakage Current I
IL
-1.0 +1.0
µ
A
I/O Leakage Current
CE>V
IH CC
I
IO
-1.0 +1.0 µ A
Output Current @2.4V I
OH
-1.0 mA
Output Current @0.4V I
OL
2.0 mA
Standby Current CE = 2.2V I
CCS1
5.0 10.0 mA
Standby Current CE = V
CC
-0.5V I
CCS2
3.0 5.0 mA
Operating Current t
CYC
=200ns
(Commercial)
I
CC01
75 mA
Operating Current t
CYC
=200ns
(Industrial)
I
CC01
85 mA
Write Protection Voltage
(DS1220AB) V
TP
4.5 4.62 4.75 V
Write Protection Voltage
(DS1220AD) V
TP
4.25 4.37 4.5 V
CAPACITANCE (t
A
=25 ° C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
5 10 pF
Input/Output Capacitance C
I/O
5 12 pF
