MAX16064
±0.3% Accurate, Quad, Power-Supply Controller with
Active-Voltage Output Control and PMBus Interface
______________________________________________________________________________________ 19
Table 1b. 16-Bit Words Stored in EEPROM (continued)
EEPROM
ADDRESS
NAME PAGE PMBus COMMAND NOTES
104–115 MFR_DATE — 9Dh —
116 MFR_STATUS_WORD — 0D8h Set to 0
118 WRITE_PROTECT — 10h —
120 ON_OFF_CONFIG 0
122 ON_OFF_CONFIG 1
124 ON_OFF_CONFIG 2
126 ON_OFF_CONFIG 3
02h —
128 VOUT_SCALE_LOOP 0
130 VOUT_SCALE_LOOP 1
132 VOUT_SCALE_LOOP 2
134 VOUT_SCALE_LOOP 3
29h —
136 OT_WARN_LIMIT — 51h
Internal representation
(temperature)
138 Reserved (set to 0) — — —
140 MFR_SET_ADDRESS — 0DBh
Low byte: I 2 C address,
high byte: reserved
142 Reserved (set to 0) — — —
144 TOFF_DELAY 0
146 TOFF_DELAY 1
148 TOFF_DELAY 2
150 TOFF_DELAY 3
64h —
152 VOUT_TRANSITION_RATE 0
154 VOUT_TRANSITION_RATE 1
156 VOUT_TRANSITION_RATE 2
158 VOUT_TRANSITION_RATE 3
27h —
160–175 Reserved (set to 0) 0 — —
176 MFR_MODE_OUTPUT 0
178 MFR_MODE_OUTPUT 1
180 MFR_MODE_OUTPUT 2
182 MFR_MODE_OUTPUT 3
0DEh —
184–199 Reserved (set to 0) — — —
200 MFR_RESET_DELAY — 0DDh —
202 MFR_RESET_OUTPUT — 0E1h —
204 Reserved (set to 0) — — —
206 MFR_TICK_RELOAD — 0D1h —
208 MFR_STATUS_WORD 0
210 MFR_STATUS_WORD 1
212 MFR_STATUS_WORD 2
214 MFR_STATUS_WORD 3
0D8h Set to 0
