MAX16064
±0.3% Accurate, Quad, Power-Supply Controller with
Active-Voltage Output Control and PMBus Interface
18 ______________________________________________________________________________________
Table 1b. 16-Bit Words Stored in EEPROM (continued)
EEPROM
ADDRESS
NAME PAGE PMBus COMMAND NOTES
16 MFR_FAULT_VOUT 0
18 MFR_FAULT_VOUT 1
20 MFR_FAULT_VOUT 2
22 MFR_FAULT_VOUT 3
0E3h
Internal representation
(voltage)
24 VOUT_COMMAND 0
26 VOUT_COMMAND 1
28 VOUT_COMMAND 2
30 VOUT_COMMAND 3
21h
Internal representation
(voltage)
32 TON_RISE 0
34 TON_RISE 1
36 TON_RISE 2
38 TON_RISE 3
61h —
40 TON_DELAY 0
42 TON_DELAY 1
44 TON_DELAY 2
46 TON_DELAY 3
60h —
48 VOUT_MARGIN_HIGH 0
50 VOUT_MARGIN_HIGH 1
52 VOUT_MARGIN_HIGH 2
54 VOUT_MARGIN_HIGH 3
25h
Internal representation
(voltage)
56 VOUT_MARGIN_LOW 0
58 VOUT_MARGIN_LOW 1
60 VOUT_MARGIN_LOW 2
62 VOUT_MARGIN_LOW 3
26h
Internal representation
(voltage)
64 TOFF_FALL 0
66 TOFF_FALL 1
68 TOFF_FALL 2
70 TOFF_FALL 3
65h —
72 OT_FAULT_LIMIT — 4Fh Internal representation
74 MFR_SAMPLE_RATE — 0D3h —
76–87 Reserved (set to 0) — — —
88 MFR_FAULT_RESPONSE 0
90 MFR_FAULT_RESPONSE 1
92 MFR_FAULT_RESPONSE 2
94 MFR_FAULT_RESPONSE 3
0D9h —
96 MFR_FAULT_RETRY 0
98 MFR_FAULT_RETRY 1
100 MFR_FAULT_RETRY 2
102 MFR_FAULT_RETRY 3
0DAh —
