MAX6901
3-Wire Serial RTC in a TDFN
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
to GND.......................................................……-0.3V to +6V
All Other Pins to GND ................................-0.3V to (Vcc + 0.3V)
Current into Any Pin..........................................................±20mA
Rate-of-Rise, V
CC
............................................................100V/µs
Continuous Power Dissipation (T
A
= +70°C)
8-Pin TDFN (derate 24.4mW/°C above +70°C) .........1951.0mW
Junction Temperature .....................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
ESD Protection (all pins, Human Body Model) ..................2000V
Lead Temperature (soldering, 10s) .................................+300°C
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +2.0V to +5.5V, T
A
= -40°C to +85°C, unless otherwise noted. Typical values are at V
CC
= +3.3V, T
A
= +25°C.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Operating Voltage Range
V
CC
2
5.5
V
V
CC
= +2.0V
0
°C < T
A
< +70
°C
110
Active Supply Current (Note 2)
I
CC
V
CC
= +5V
0
°C < T
A
< +70
°C
800
µA
V
CC
= +2.0V
0.4
0.7
Timekeeping Supply Current
(Note 3)
I
TK
V
CC
= +5V
1.3
1.7
µA
32kHz OUTPUT
V
CC
= +2.0V, I
SOURCE
= -0.4mA
1.8
Output High Voltage (Note 5)
V
OH
V
CC
= +5.0V, I
SOURCE
= -1mA
4.5
V
V
CC
= +2.0V, I
SINK
= 1.5mA
0.4
Output Low Voltage (Note 5)
V
OL
V
CC
= +5.0V, I
SINK
= 4mA
0.4
V
Duty Cycle
40
%
Output Leakage Current
V
IN
= 0 to V
CC
, 32kHz output disabled
-10
10
nA
3-WIRE DIGITAL INPUTS AND OUTPUTS (SCLK, I/O, CS)
V
CC
= +2.0V
1.4
Input High Voltage
V
IH
V
CC
= +5.0V
2.2
V
V
CC
= +2.0V
0.6
Input Low Voltage
V
IL
V
CC
= +5.0V
0.8
V
Input Leakage Current
V
IN
= 0 to V
CC
-10
10
nA
SCLK, RST Capacitance
5
pF
I/O Capacitance
10
pF
V
CC
= +2.0V, I
SINK
= 1.5mA
0.4
I/O Output Low Voltage
V
OL
V
CC
= +5.0V, I
SINK
= 4mA
0.4
V
V
CC
= +2.0V, I
SOURCE
= -0.4mA
1.8
I/O Output High Voltage
V
OH
V
CC
= +5.0V, I
SOURCE
= -1mA
4.5
V
