8
T5754
4511D–RKE–08/02
Figure 8. ESD Protection Circuit
CLK PA_ENABLE ANT2
ANT1
XTAL ENABLE
VS
GND
Absolute Maximum Ratings
Parameters Symbol Minimum Maximum Unit
Supply voltage V
S
5 V
Power dissipation P
tot
100 mW
Junction temperature T
j
150 ° C
Storage temperature T
stg
-55 125 ° C
Ambient temperature T
amb
-55 125 ° C
Thermal Resistance
Parameters Symbol Value Unit
Junction ambient R
thJA
170 K/W
Electrical Characteristics
V
S
= 2.0 V to 4.0 V, T
amb
= -40°C to 125°C unless otherwise specified.
Typical values are given at V
S
= 3.0 V and T
amb
= 25°C. All parameters are refered to GND (Pin 7).
Parameters Test Conditions Symbol Min. Typ. Max. Unit
Supply current Power down,
V
ENABLE
< 0.25 V, -40°C to 85°C
V
PA-ENABLE
< 0.25 V, -85°C to +125 ° C
V
PA-ENABLE
< 0.25 V, 25°C
(100% correlation tested)
I
S_Off
<10
350
7
nA
µ A
nA
Supply current Power up, PA off, V
S
= 3 V,
V
ENABLE
> 1.7 V, V
PA-ENABLE
< 0.25 V
I
S
3.7 4.8 mA
Supply current Power up, V
S
= 3.0 V,
V
ENABLE
> 1.7 V, V
PA-ENABLE
> 1.7 V
I
S_Transmit
9 11.6 mA
Output power V
S
= 3.0 V, T
amb
= 25 ° C,
f = 433.92 MHz, Z
Load
= (166 + j233) W
P
Ref
5.5 7.5 10 dBm
