MAX5440
Stereo Volume Control
with Rotary Encoder Interface
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
SHDN, MUTE, RENCODEA, RENCODEB,
and MODE to GND............................-0.3V to (V
LOGIC
+ 0.3V)
H_, L_, and W_ to V
SS
...............................-0.3V to (V
DD
+ 0.3V)
LEDIND_, MODEIND to GND................-0.3V to (V
LOGIC
+ 0.3V)
MIDBIAS, BIAS to V
SS
......................(V
SS
- 0.3V) to (V
DD
+ 0.3V)
V
LOGIC
to GND...........................................-0.3V to (V
DD
+ 0.3V)
V
DD
to GND ..............................................................-0.3V to +6V
V
DD
to V
SS
................................................................-0.3V to +6V
V
SS
to GND...............................................................-3V to +0.3V
Input and Output Latchup Immunity...............................±200mA
Continuous Power Dissipation (T
A
= +70°C)
24-Pin SSOP (derate 8mW/°C above +70°C) ..............640mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-60°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
ELECTRICAL CHARACTERISTICS
(V
DD
= +2.7V to +5.5V, V
SS
= GND = 0, 2.7V
≤ (V
DD
- V
SS
)
≤ 5.5V, V
LOGIC
= +2.7V to V
DD
, V
H_
= V
DD
, V
L_
= V
DD
/ 2, T
A
= T
MIN
to
T
MAX
, unless otherwise specified. Typical values are at T
A
= +25°C.) (Note 1)
2
_______________________________________________________________________________________
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
End-to-End Resistance
R
36
40
52
k
Ω
Absolute Tolerance
±0.25
dB
Tap-to-Tap Tolerance
±0.1
dB
V
H _
= ( V
D D
/ 2) + 1V
RM S
, 1kH z tap at top , R
L
=
∞ to V
L_
= V
D D
/ 2, 20H z to 20kH z
0.004
V
H _
= ( V
D D
/ 2) + 1.5V
RM S
, 1kH z tap at top ,
R
L
=
∞ to V
L_
= V
D D
/ 2, 20H z to 20kH z
0.006
V
DD
= 5V,V
SS
= 0V, V
L_
= 1.5V, V
H_
=
(V
DD
/ 2) + 1V
RMS
, 1kHz tap at top, R
L
=
10k
Ω to V
MIDBIAS
, 20Hz to 20kHz
0.004
Total Harmonic Distortion Plus
Noise
THD+N
V
DD
= 5V,V
SS
= 0V, V
L_
= 5V, V
H _
= ( V
D D
/
2) + 1.5V
RM S ,
1kHz tap at top, R
L
= 10k
Ω
to V
MIDBIAS
, 20Hz to 20kHz
0.006
%
Channel Isolation
100
dB
Interchannel Matching
±0.5
dB
Mute Attenuation
SHDN = V
DD
90
dB
Power-Supply Rejection Ratio
PSRR
Input referred, 217Hz, 100mV
P-P
on V
DD
-60
dB
H Terminal Capacitance
C
H
5
pF
L Terminal Capacitance
C
L
7
pF
End-to-End Resistance
35
ppm/°C
Ratiometric Resistance
5
ppm/°C
Bandwidth, -3dB
f
CUTOFF
C
W
= 33pF
100
kHz
Output Noise
e
n
20Hz to 20kHz
3.2
µV
RMS
WIPER BUFFER
Output Voltage Swing
V
O
R
L
= 10k
Ω to V
MIDBIAS
V
DD
- 0.2
V
Output Current
3
mA
Output Resistance
R
OWB
1
10
Ω
DC Offset
-5
±2
+5
mV
INTEGRATED BIAS GENERATOR
Output Voltage
I
LOAD
= 1mA
(V
DD
+
V
SS
) / 2
- 10mV
(V
DD
+
V
SS
)
/ 2
( V
D D
+
V
S S
) / 2 +
10m V
V
